Side 1/18
Read this user manual and in
particular the safety notes,
before using the product.
Keep the user manual for future
reference and include it when passing the
product on to third parties.
Esprinet S.p.A. will not in any way be held
responsible for injury or damage caused to
persons or property arising from misuse of
the product.
Avoid listening at extreme volumes,
particularly for prolonged periods of time
when using the product.
If you use the product at an excessively high
volume, you could permanently damage your
hearing. Listen at a moderate volume.
Be aware of how these signals differ in terms
of their sound so that you are able to recognize
the signals in corresponding situations.
Observe the legal regulations and provisions in
the country where you use the product.
To prevent malfunction or damage to the
product, avoid accidental falls, do not crush,
puncture or exercise a high level of pressure
on the product.
Do not store or expose your product to any
source of heat, direct sunlight, radiators,
stoves or other heat sources such as the
dashboard of your car in the summer.
Do not try to modify, repair or disassemble the
product.
Do not use a damaged product.
Do not under any circumstances use
aggressive cleaning agents, alcohol or other
chemical solutions for cleaning as they can
damage the housing or even impair the
functionality of the product.
ere are no serviceable parts inside the
product. Never open/disassemble it.
Keep the product out of reach of children.
Never allow children or persons with
disabilities to use electrical products without
supervision.
Make sure children do not remove any small
parts from the product: they may swallow
them when playing and suffocate.
Charging
For the first use, recharge the device until
it is fully charged. To recharge the product,
use the included charging cable. e red light
indicates that the product is in the charging
state, when the light goes out the device will
be fully charged.
Pairing
Place the speaker and pairing device within
1 meter of each other. Enable the wireless
function of the device you intend to pair
with. Activate your pairing device’s wireless
feature. Search for “KHSPEAKER” and select
it to connect. If a password is requested, key
in “0000”.
Automatic reconnection
Once the product and the pairing device
have been paired, they will automatically
reconnect if they are within a short distance
of each other and the pairing device's wireless
function is enabled.
TWS function
1. Power on 2 KHSPEAKER speakers at the
same time, a blue light will flash on both. Press
the TWS button on both speakers, after a few
seconds the speakers will pair with each other,
a steady green light will appear on both.
2. Open the wireless menu on your device,
Search for the device from the wireless
menu and select "KHSPEAKER" to start the
connection
3. Once pairing is complete, you will hear a
sound, a blue light will flash on both speakers.
It is now possible to play music from both
speakers simultaneously.
4. Press the TWS button on either speaker to
exit TWS mode. Press the TWS button again
to pair again, Two previously paired speakers
will automatically reconnect once turned on.
TF CARD MODE
To switch from wireless mode to playing TF
card content, insert the card into the card slot
of the product and hold down the “M” key.
After 5 seconds, the new playback mode will
automatically start.
e maximum capacity allowed is 32 GB.
Multifunction buttons
Cleaning
Do not use solvents, corrosive agents or
gaseous cleaners.
Technical specifications
Wireless Version: 5.0
Inputs: DC 5V/0.5A
Battery life: 10h
Charging time: 2.5h
Speaker diameter: Ø 52mm
Impedance: 4Ω
Frequency Response: 20Hz~20KHz
Frequency: 2.408-2.480GHz
Maximum radiated power: <20mW
Outputs: 5W
Battery: 3.7V/1200mAh, 4.44Wh
Size: 10.1x7.6x7.6cm
Weight: 262g
Wireless range: 10m
Usage temperature: 0-40°
CUSTOMER’S INFORMATION FOR
RIGHT WASTE OF THIS PRODUCT
(Directive 2013/56/EU)
is marking on the product or its packaging
means that the product at the end of its life,
inlcuding the unremovable battery, must
be separated from other types of waste to
recycle it responsibly.
Safely’s use of this product is guaranteed from
the respect of this instructions manual, keep it
and carefully use it for all life of the product.
e product doesn’t need any kind of technical
maintenance, NEVER DISASSEMBLE IT.
e battery inside the product is integrated
and not replaceable. Don not try to remove
li-ion/polymer battery included in inside the
product because can produce overheat’s
danger, burning and injury. e battery must
be removed only by qualified professional
techincians, that are able to remove it without
any kind of danger and to recycle it in the
respect of the law. Users should give free end
of life product into the local separate collection
centers or to the retailer, in reason of one to
one, or free if the product size is bigger than
25 cm. Adequated waste disposal permit to
award the product to recycling, treatment
with ecofriendy compatible disposal conduce
to prevent possible harm to the environment
or human health and promote the reuse and/
or product materials recycling. Unauthorized
waste disposal of electronic product, cell and
battery from houseold user involve currency
legislation sanctions.
is product complies with RoHS
directive 2011/65/EU –
2015/863/EU. e Product has the
CE mark and therefore complies with the
safety standards established by the European
Union.
Esprinet SpA declares that the product
complies with directive 2014/53/EU.
e full text of the EU declaration of
conformity is available at the following
internet address:
www.celly.com/exchange/CELLY-SPA/
Dichiarazioni_di_conformita/KHSPEAKER/
DOC_KHSPEAKER.pdf
© Keith Haring Foundation.
www.haring.com, Licensed by Artestar,
New York.
Produced under license by
Esprinet Spa,
Via Energy Park 20, 20871 –
Vimercate – MB (Italy)
Made in China
Instruction manual
WIRELESS SPEAKER
Model: KHSPEAKER
Rev00 - 08.03.2023
FUNCTION SINGLE CLICK LONG PRESS
POWER // ON/OFF
+ NEXT TRACK VOLUME +
- PREVIOUS TRACK VOLUME -
PLAY/PAUSE PLAY/PAUSA //
M TF CARD WIRELESS ON/OFF
EN
