Side 1/18

Read this user manual and in

particular the safety notes,

before using the product.

Keep the user manual for

future reference and include it when

passing the product on to third parties.

Esprinet S.p.A. will not in any way be held

responsible for injury or damage caused to

persons or property arising from misuse of

the product.

Safety notes

Avoid listening at extreme volumes,

particularly for prolonged periods of time

when using the product.

If you use the product at an excessively

high volume, you could permanently

damage your hearing. Listen at a

moderate volume. Be aware of how these

signals diﬀer in terms of their sound so

that you are able to recognize the signals

in corresponding situations. Observe the

legal regulations and provisions in the

country where you use the product. To

prevent malfunction or damage to the

product, avoid accidental falls, do not

crush, puncture or exercise a high level

of pressure on the product. Do not store

or expose your product to any source of

heat, direct sunlight, radiators, stoves or

other heat sources such as the dashboard

of your car in the summer. Do not try to

modify, repair or disassemble the product.

Do not use a damaged product.

Do not under any circumstances use

aggressive cleaning agents, alcohol or

other chemical solutions for cleaning as

they can damage the housing or even

impair the functionality of the product.

ere are no serviceable parts inside the

product. Never open/disassemble it. Keep

the product out of reach of children. Never

allow children or persons with disabilities

to use electrical products without

supervision.

Make sure children do not remove any

small parts from the product: they may

swallow them when playing and suﬀocate.

Charging

For the ﬁrst use, recharge the device until

it is fully charged. To recharge the product,

use the included charging cable. e red

light indicates that the product is in the

charging state, when the light disappears

the device will be fully charged.

Pairing

Place the speaker and pairing device

within 1 meter of each other. Enable the

wireless function of the device you intend

to pair with.

Activate your pairing device’s wireless

feature. Search for “GROOVERGB” and

select it to connect. If a password is

requested, key in “0000”.

Automatic reconnection

Once the product and the pairing device

have been paired, they will automatically

reconnect if they are within a short

distance of each other and the pairing

device's wireless function is enabled.

TWS function

1. Power on 2 GROOVERGB speakers at

the same time. Press the TWS button on

both speakers, after a few seconds the

speakers will pair with each other, a sound

will announce the correct pairing.

2. Open the wireless menu on your device,

Search for the device from the wireless

menu and select "GROOVERGB" to start

the connection

3. Once pairing is complete, you will hear

a sound. It is now possible to play music

from both speakers simultaneously.

4. Press the TWS button on either

speaker to exit TWS mode. Press the

TWS button on both speakers to pair

again, two previously paired speakers will

automatically reconnect once turned on. If

not press the TWS button on one of the

two speakers.

Cleaning

Do not use solvents, corrosive agents or

gaseous cleaners.

Multifunction buttons Technical speciﬁcations

Wireless version: 5.1

Input: DC 5V/500mAh

Battery life: up to 3h

Charging time: 2h

Speaker diameter: Ø 51mm + 51mm

Impedance: 2Ω

Frequency response: 150Hz ~ 18KHz

Frequency: 2,408-2,480 GHz

Maximum radiated power: <20m.W

Output: 10W (5W+5W)

Battery: 1800mAh / 5,55Wh

Size: 9x7,9x25.9cm

Weight: 630g

Wireless range: 10m

Temperature of use: 0-40 °

CUSTOMER’S INFORMATION

FOR RIGHT WASTE OF THIS

PRODUCT (Directive 2013/56/

EU)

is marking on the product or its

packaging means that the product at the

end of its life, inlcuding the unremovable

battery, must be separated from other

types of waste to recycle it responsibly.

Safely’s use of this product is guaranteed

from the respect of this instructions

manual, keep it and carefully use it for all

life of the product.

e product doesn’t need any kind

of technical maintenance, NEVER

DISASSEMBLE IT.

e battery inside the product is

integrated and not replaceable. Don

not try to remove li-ion/polymer battery

included in inside the product because can

produce overheat’s danger, burning and

injury. e battery must be removed only

by qualiﬁed professional techincians, that

are able to remove it without any kind of

danger and to recycle it in the respect of

the law. Users should give free end of life

product into the local separate collection

centers or to the retailer, in reason of one

to one, or free if the product size is bigger

than 25 cm. Adequated waste disposal

permit to award the product to recycling,

treatment with ecofriendy compatible

disposal conduce to prevent possible

harm to the environment or human

health and promote the reuse and/ or

product materials recycling. Unauthorized

waste disposal of electronic product, cell

and battery from houseold user involve

currency legislation sanctions.

is product complies with the

RoHS directive 2011/65 / EU -

2015/863 / EU. e Product has

the CE mark and therefore complies with

the safety standards established by the

European Union.

Esprinet SpA declares that the product

complies with directive 2014/53 / EU.

e full text of the EU declaration of

conformity is available at the following

internet address:

w w w . c e l l y . c o m / e x c h a n g e / C E L LY -

S P A / D i c h i a r a z i o n i _ d i _ c o n f o r m i t a /

GROOVERGBBK/DOC_GROOVERGBBK.

pdf

Celly® is a trademark owned by Esprinet

S.p.A.

All brands are registered trademarks of

their respective owners.

Esprinet S.p.A., via Energy Park

20, 20871 Vimercate (MB) -

Italy

Made in China.

Instruction manual

WIRELESS SPEAKER

Model: GROOVERGB

Rev00 - 13.04.2023

FUNCTION SINGLE CLICK LONG PRESS

POWER // ON/OFF

+ Volume + Next track

- Volume - Previous track

Play/Pause - TWS Play/pausa TWS mode ON/OFF

M Light pattern switch TF/AUX/Wireless mode

switch

Produkt Specifikationer

Mærke:	Celly
Kategori:	Højttaler
Model:	Groovergb
Bredde:	685 mm
Dybde:	85 mm
Højde:	255 mm
Vægt:	150 g
Produktfarve:	Sort
Batterikapacitet:	500 mAh
Indbygget skærm:	Ingen
Wi-Fi:	Ingen
FM radio:	Ingen
Batteriteknologi:	Lithium-Ion (Li-Ion)
Antal højttalere:	1
Udgangseffekt (RMS):	10 W
Volumenkontrol:	Knapper
Husmateriale:	Plast
Pakketype:	Kasse
Anbefalet brug:	Universel
Impedens:	2 ohm (Ω)
Forbindelsesteknologi:	Trådløs
Standby tid:	48 t
Indbygget kortlæser:	Ingen
Styrehjul:	Ingen
USB-tilslutning:	Ja
Batteritype:	Indbygget batteri
Opladningstid for batteri:	2 t
Indbygget mikrofon:	Ingen
Driver diameter:	51 mm
USB-stik type:	USB Type-C
Belysningsfarve:	Blue, Green, Red
Bluetooth-område:	10 m
USB-opladningsport:	Ja
Belysning LED:	Ja
