SMK-7

Item ref: 173.6 44UK

Studio Mic Kit

User Manual

Introduction

Th SMK-7 is a complete studio microphone oute fit for recording vocals and instruments into a mixing

console which has balanced inputs with phantom power. Th kit comprises a large diaphragm condenser e

microphone, shock-proof holder, foam pop filter, vocal pop screen angle-poise boom arm with worktop ,

clamp and a balanced XLR male to female lead.

Setting up

Attach the boom arm clamp to a desk or worktop by opening the

clamp to slide onto the edge of the worktop with the cone on the

top and tightening the underside screw clamp until it is firmly

attached. The boom arm fits onto the clamp by slotting the black

tube end into the hole in the cone at the top of the clamp.

To mount the microphone on the boom arm, push the microphone

(connector end first) into the shock-proof holder until it is held

firmly and then screw the base of the holder onto the threaded

adaptor on the silver end of the boom arm.

Adjust and tighten the base of the mic holder at the required angle

and use the angle poise mechanism to position the microphone

where needed.

If required, place the foam pop filter over the microphone grille and/or attach the gooseneck clamp of the

pop screen to the angle-poise boom arm for positioning the screen in front of the microphone In addition .

to reducing pops and sibilance, this screen can be used to help maintain the mouth distance from the

microphone for a more consistent vocal level.

Connect the female end of the supplied XLR lead to the microphone XLR connector and the male end (with

3 pins) to balanced input on the mixing console or recording device, ensuring that the output volume level a

is turned fully down or muted before connecting. Enable phantom power (+5V to +48V) to the XLR input

before

turning up the output level .

Check that the microphone is positioned correctly by increasing the volume whilst speaking into the

microphone and checking the output. Th voice should be clear and not muffled. If the voice is muffled, e

turn the microphone around until the front of the capsule is facing toward you, which should produce more

detail and full frequency response.

Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as

Electrical or Electronic equipment and should not be disposed with other household or commercial waste

at the end of its useful life. The goods must be disposed of according to your local council guidelines.

Unit 2-4 Bridgewater Park, Taylor Rd. Manchester. M41 7JQ

AVSL (EUROPE) Ltd, Unit 3D North Point House, North Point Business Park, New Mallow Road, Cork, Ireland

Produkt Specifikationer

Mærke:	Citronic
Kategori:	Mikrofon
Model:	SMK-7
Type:	Studiemikrofon
Bredde:	157 mm
Dybde:	46 mm
Produktfarve:	Sort
Forbindelsesteknologi:	Ledningsført
Strømkilde:	DC
Enhedsgrænseflade:	2.5 mm (2/32")
Indgangsspænding:	5-48 V
Mikrofonindgangsimpedans:	150 ohm (Ω)
Mikrofon frekvens:	20 - 20000 Hz
Mikrofon sensitivitet:	-38 dB
Mikrofon vægt:	228 g
Mikrofon, signal-til-støjforhold:	78 dB
