CU-POD

Item ref: 173.632UK

Podcast Microphone Set

User Manual

Setting up

Mount the CU-POD to the supplied angle-adjustable holder

by rotating it onto the Mounting Thread at the base of the

microphone, surrounding the USB socket.

This holder can be attached to the supplied mini tripod stand

for tabletop use or attached to a standard microphone stand

or boom arm

(an adaptor is provided for s tands with 3/8” threads)

A foam pop shield is provided, which may be used if air noise

or popping is obtrusive when recording the microphone.

Connect the supplied USB lead to the type B Socket at the

base of the microphone housing and the other end to an

available USB port on a PC or Mac computer.

The computer will recognise the CU-POD as a USB Audio Device for both input and output of audio.

Connect headphones to the 3.5mm Headphones Output on the front of the CU-POD

Operation

Selecting the CU-POD (usually appearing as “USB Audio Device”) as the input and output device

within the recording software will set the microphone as the input source and the headphones output

for the output for monitoring.

All audio that would normally come from the computer speakers will no w be routed to the

headphones output of the CU-POD.

Set the VOL (volume) control to the required level so that the sound is clear and not distorted.

Speak into the front of the grille (the front side is with the controls facing you) approximately 5cm

away from the grille.

Press ing MUTE will mute the microphone – pressing this again will un-mute the microphone.

If an echo effect is required, this can be introduced by turning up the ECHO control, otherwise,

turning this control fully down removes this effect.

The CU-POD can be disconnected and re-connected to USB as a hot-swappable device.

Disconnect from USB after use to preserve the computer battery or power supply.

173.632UK User Manual

Specifications

Capsule

15mmØ back-electret condenser

Polar pattern

Cardioid

Connection

USB type B (power & digital audio)

Lead length

1.4m

Headphone: connector

3.5mm s tereo jack

Frequency response

30Hz - 20kHz

Controls

Echo, Volume & Mute

Max. SPL

120dB

SNR

10dB

Sensitivity

25mV/Pa (-32dB±2dB)

Dimensions

158 x 45mmØ

Weight

228g

Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as Electrical or

Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life.

The goods must be disposed of according to your local council guidelines.

Errors and omissions excepted.
