CLUB3D CSP-D850CB, 850Watt 80+ Bronze Cable Management Manual

CLUB3D Computer strømforsyning CSP-D850CB, 850Watt 80+ Bronze Cable Management

Læs gratis den danske manual til CLUB3D CSP-D850CB, 850Watt 80+ Bronze Cable Management (1 sider) i kategorien Computer strømforsyning. Denne vejledning er vurderet som hjælpsom af 30 personer og har en gennemsnitlig bedømmelse på 4.8 stjerner ud af 15.5 anmeldelser. Har du et spørgsmål om CLUB3D CSP-D850CB, 850Watt 80+ Bronze Cable Management, eller vil du spørge andre brugere om produktet?

Download PDF

Side 1/1

Cable loom (mm)

20+4P Main

ATX/EPS 4+4P

PCI-E 6+2P

Input Characteristics

Input Current

15A

Total Max.

Output

850W

+3.3V +5V +12V1 +12V2 +12V3 +5VSB

24A 30A 34A 34A 34A 34A

170W 732W 6W 15W

829W 21W

0.5A 3.0A

-12V2+12V4

Output Characteristics

Item

Code

CSP-D850CB

Voltage

115V-230V

Frequency

50-60Hz

135mm Fan

Cable Management

Extremely Low Noise

Safety Protections

trademarks and are the property of their respective owners.All specifications are subject to change without notice.

Made for PC with single VGA configurations.

CSP-S400

400 Watt

CSP-S600

600 Watt

CSP-D700CB

700 Watt

CSP-D850CB

850 Watt

CSP-X1000CB

1000 Watt

Made for PC with dual VGA configurations.

Made for PC with triple VGA configurations.

S W I T C H I N G P O W E R S U P P L Y

Modular CableNative Cable

1x 20+4 pin main

connector

3x SATA connector

1x ATX12V/EPS12V

4+4 pin connector

2x PCI Express 6+2 pin

connector

1x Floppy connector

6x SATA connector

1x ATX12V/EPS12V

4+4 pin connector

Item Code: CSP-D850CB

EAN Code: 8717249408710

550

550+150

SATA

PATA+FLOPPY

550+150

www.club-3d.com

• User manual

• Power cord

• 3x Velcro wraps for cable management

• Carrying bag

• Modular cables

Specification

Type

PFC

Input Voltage

Input Frequency Range

Fan

Power Good Signal

Hold Up Time

Efficiency (Load)

Dimensions (W / D / H)

Operation Temperature

Safety

80-PLUS Certification

Protection

Features

• Compatible with latest PC-technology

Supports the newest specifications of ATX12V & EPS12V. Supports current and next-generation multi-CPU and GPU

platforms (including ATI Crossfire and NVIDIA SLI configurations).

• Extremely high efficiency (80-Plus® Bronze certification)

Up to 85% of efficiency, compliant with 80-Plus® Bronze efficiency requirement.

• Highly durable & reliable 105°C and 85°C capacitors

The best solution for a High-end PSU by using 105°C and 85°C capacitors.

• Ultra-quiet fan

Extremely Low Noise Level, equipped with a large and ultra-quiet 135mm fan.

Included in the box

• Switching Power Supply unit

• Switching Power Supply unit thumbscrews

• Switching Power Supply unit bag

ATX Form Factor 12V V2.3 / SSI standard EPS 12V V2.92

Active PFC (0.99)

100-240V (Auto Range)

50 ~ 60Hz

Ultra-silent 135mm temperature controlled fan

100 ~ 500ms

> 17ms

85%

Standard ATX 150 x 165 x 86 (mm)

0-40°C (nominal Input Voltage)

80PLUS Bronze

OCP (Over Current Protection), UVP (Under Voltage Protection),

OVP (Over Voltage Protection), SCP (Short Circuit Protection),

OPP (Over Power Protection)

2x PCI Express 6+2 pin

connector

1x Floppy connector

2x Peripheral connector

5x Peripheral connector

Produkt Specifikationer

Mærke:	CLUB3D
Kategori:	Computer strømforsyning
Model:	CSP-D850CB, 850Watt 80+ Bronze Cable Management
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	115 - 230 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	150 mm
Dybde:	165 mm
Højde:	86 mm
Brugervejledning:	Ja
Produktfarve:	Black, Green
Strømforsyningstype:	Vekselstrøm/jævnstrøm
Dimensioner (BxDxH):	150 x 165 x 86 mm
Støjniveau:	10 dB
Certificering:	CE, 80Plus Bronze
Bæredygtighedscertifikater:	RoHS, ENERGY STAR
Formål:	PC
Indgangsstrøm:	15 A
Total effekt:	850 W
Antal blæsere:	1 blæser(e)
Strømbeskyttelsesfunktioner:	Over current, Over power, Over voltage, Short circuit, Under voltage
Effektivitet:	85 %
Strømkorrektionsfaktor (PFC):	Aktiv
Maksimal indgangsstrøm (@ 110V):	+12V1, +12V2, +12V3, +12V4, +3.3V, +5V, +5Vsb, -12V A
Kombineret effekt (+3,3 V):	170 W
Kombineret effekt (+12 V):	732 W
Kombineret effekt (+5 V):	170 W
Maks. udgangsstrøm (+3,3 V):	24 A
Maks. udgående strøm (+12 V1):	34 A
Maks. udgående strøm (+12 V2):	34 A
Maks. udgående strøm (+12 V3):	34 A
Maks. udgående strøm (+12 V4):	34 A
Maks. udgangsstrøm (+5 V):	30 A
Maks. udgangsstrøm (-12V):	0.5 A
Maks. udgangsstrøm (+5 VSB):	3 A
Holdetid:	17 ms
Strømforsyningenhed (PSU) formfaktor:	ATX
ATX-version:	2.3
EPS-version:	2.92
80 PLUS certificering:	80 PLUS Bronze
Ventilator diameter:	135 mm
Kølingstype:	Aktiv
Motherboard, strømstik:	20+4 pin ATX
Antal SATA strømstik:	9
Perifere (Molex) strømstik (4-pin):	5
PCI ekspres strømforbindelser (6+2 pin):	6
CPU strømstik (4+4 pin):	Ja
Diskettedrev, strømstik:	2
Kabeltype:	Semi-modulær
Kombineret effekt (-12V):	6 W
Kombineret effekt (+5 VSB):	15 W
Floppy-drev, stik:	Ja
PCI Express stik:	Ja
ATX strømstik (20+4 pin):	Ja
Antal PATA strømstik:	2
