Side 1/1

Cable loom (mm)

20+4P Main

PCI-E 6+2P

ATX/EPS 4+4P

Input Characteristics

Input Current

10A

Total Max.

Output

600W

+3.3V +5V +12V1 +12V2 +5VSB

24A 24A 22A 22A

150W 432W 6W 12.5W

581.5W 18.5W

0.5A 2.5A

-12V2

Output Characteristics

Item

Code

CSP-S600

Voltage

110V-240V

Frequency

50-60Hz

120mm Fan

Extremely Low Noise

Safety Protections

trademarks and are the property of their respective owners.All specifications are subject to change without notice.

Made for PC with single VGA configurations.

CSP-S400

400 Watt

CSP-S600

600 Watt

CSP-D700CB

700 Watt

CSP-D850CB

850 Watt

CSP-X1000CB

1000 Watt

Made for PC with dual VGA configurations.

Made for PC with triple VGA configurations.

S W I T C H I N G P O W E R S U P P L Y

Native Cable

5x Peripheral connector

1x 20+4 pin main

connector

1x Floppy connector

6x SATA connector

1x ATX12V/EPS12V

4+4 pin connector

Item Code: CSP-S600

EAN Code: 8717249408697 R1

550

550+150

550

SATA

PATA+FLOPPY

550+150

www.club-3d.com

2x PCI Express 6+2 pin

connector

Specification

Type ATX Form Factor 12V V2.3

PFC Active PFC (0.99)

Input Voltage 100-240V (Auto Range)

Input Frequency Range 50 ~ 60Hz

Fan Ultra-silent 120mm temperature controlled fan

Power Good Signal 100 ~ 500ms

Hold Up Time > 17ms

Efficiency (Load) 85%

Dimensions (W / D / H) Standard ATX 150 x 140 x 86 (mm)

Operation Temperature 0-40°C (nominal Input Voltage)

Safety CE

80-PLUS Certification 80PLUS Bronze

Protection OCP (Over Current Protection), UVP (Under Voltage

Protection), OVP (Over Voltage Protection), SCP (Short

Circuit Protection), OPP (Over Power Protection)

Features

• Compatible with latest PC-technology

Supports the newest specifications of ATX12V. Made for single VGA card configurations.

• Extremely high efficiency (80-Plus® Bronze certification)

Up to 85% of efficiency, compliant with 80-Plus® Bronze efficiency requirement.

• Highly durable & reliable 105°C and 85°C capacitors

The best solution for a High-end PSU by using 105°C and 85°C capacitors for 12V.

• Ultra-quiet fan

Extremely Low Noise Level, equipped with a large and ultra-quiet 120mm fan.

Included in the box

• Switching Power Supply unit

• Switching Power Supply unit thumbscrews

• Switching Power Supply unit bag

• User manual

• Power cord

• 3x Velcro wraps for cable management

Produkt Specifikationer

Mærke:	CLUB3D
Kategori:	Computer strømforsyning
Model:	CSP-S600
Tænd-/slukkontakt:	Ja
Vekselstrømsindgangsspænding:	100 - 240 V
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	150 mm
Dybde:	165 mm
Højde:	86 mm
Brugervejledning:	Ja
Produktfarve:	Black, Yellow
Strømforsyningstype:	Vekselstrøm/jævnstrøm
Dimensioner (BxDxH):	150 x 140 x 86 mm
Støjniveau:	16 dB
Certificering:	CE, 80Plus
Bæredygtighedscertifikater:	RoHS, ENERGY STAR
Formål:	PC
Indgangsstrøm:	10 A
Total effekt:	600 W
Strømbeskyttelsesfunktioner:	Over current, Over power, Over voltage, Short circuit, Under voltage
Effektivitet:	85 %
Strømkorrektionsfaktor (PFC):	Aktiv
Kombineret effekt (+3,3 V):	150 W
Kombineret effekt (+12 V):	432 W
Kombineret effekt (+5 V):	150 W
Maks. udgangsstrøm (+3,3 V):	24 A
Maks. udgående strøm (+12 V1):	22 A
Maks. udgående strøm (+12 V2):	22 A
Maks. udgangsstrøm (+5 V):	24 A
Maks. udgangsstrøm (-12V):	0.5 A
Maks. udgangsstrøm (+5 VSB):	12.5 A
Holdetid:	17 ms
Strømforsyningenhed (PSU) formfaktor:	ATX
ATX-version:	2.4
EPS-version:	2.92
80 PLUS certificering:	80 PLUS Bronze
Ventilator diameter:	120 mm
Kølingstype:	Aktiv
Motherboard, strømstik:	20+4 pin ATX
Antal SATA strømstik:	6
Perifere (Molex) strømstik (4-pin):	5
CPU strømstik (4+4 pin):	Ja
Diskettedrev, strømstik:	1
Kombineret effekt (-12V):	6 W
Kombineret effekt (+5 VSB):	12.5 W
Floppy-drev, stik:	Ja
PCI Express stik:	Ja
PCI ekspres strømstik (8-pin):	1
ATX strømstik (20+4 pin):	Ja
