Thank you for choosing COLBOR product. Please read this manual
carefully before use and follow all instructions mentioned herein.
CTRL1 Remote Dimming Control User Manual
Caring For Your COLBOR Product
Product Instructions
Please read the manual carefully before using this product.
Keep corrosive chemicals, liquids, heat source away from the
product to prevent mechanical damage.
This product is not waterproof, please do not operate it with wet
hands.
The product is not waterproof. Do not handle with wet hands.
Do not attempt to disassemble or modify the product. Please
have the product checked or repaired by authorized technicians
if any malfunctions happened.
Malfunction may be caused by dropping or external force, any
man-made damage is not covered by our warranty.
Our company reserves the right of nal interpretation of the
product.
① Turntable
② Anti-slip Pad
③ Battery Cell
Application of the product:
Note:
The above products that meet the requirements of the hardware
version should be upgraded to the rmware version "1.0.6"
through EdgeMax APP before used with CTRL1. You can check
the hardware version and rmware version in Product Information
under Setting mode.
Product Model
CL60
CL60M
CL60R
CL100X
CL100XM
CL220
CL220M
Support CTRL 1 or notHardware Version
1.0.1
1.0.2 and above
1.0.1
1.0.2 and above
1.0.1 / 1.0.2 / 1.0.3
1.0.4
1.0.1 and above
1.0.1 and above
1.0.1 and above
1.0.1 and above
* The hardware version is the production batch version and the
rmware version is the product runtime version.
Operation Instructions
1. Replace the battery
The product uses CR2450 button battery, and users can purchase
it if they have additional needs.
When replacing the battery, place the remote control on the
desktop. Hold the lower part and press down gently to make
the non-slip pad close to the desktop. At the same time, turn it
counterclockwise to open the battery compartment.
LockUnlock
* Note:
1). When using this product for the rst time, please open the
battery cover and pull out the battery insulation strip.
2). The silicone anti-skid pad at the bottom of the product is only
used for desktop anti-skid. Do not stick the product vertically to
avoid falling and damage. Anti-slip mat will adhere to more dust
with the use of time, resulting in decreased adsorption force. Use
wet tissue to clean it and the adsorption force will be improved.
3. Remote control switch on/o
CL60 and CL100X series：Long press the turntable for 3 seconds
to turn on, long press the turntable for 2 seconds to turn o.
CL220 series：Long press the turntable 3 seconds light to zero.
* CL220 series uses a physical switch to manage the power
supply of the lamps. Therefore, CTRL1 can only be used after be
turned on.
＊ Start up from sleep
The remote control enters the sleep state after no operation for 3
minutes. You need to start it up by rotating, clicking, or double-
clicking to continue the operation.
2. Product pairing
① Setting the lamp and select the wireless connection mode to
remote control. Short press the lower dial wheel of the lamp, and
the wireless connection status icon in the upper left column of the
lamp screen ashes, and the lamp enters the pairing mode.
* Note: Only wireless connection options with rmware version
"1.0.6" have APP and remote control options.
② Short press a turntable, and then long press 3~4 seconds, the
control began to match with the lamp.
③ After the wireless connection on the lamp panel is displayed as
"Remote control paired", release Ctrl 1 and the lamp and remote
control have been paired successfully.
* Note:
After remote control is selected as the wireless connection mode,
the lamp and the mobile phone APP unpaired, and the cannot
control with APP. Similarly, if the wireless connection mode is
APP, the remote control cannot be used.
The lamps that have been paired successfully can be switched
back to the remote control from APP without pairing again.
1X
1X
4. Switching options
Press the turntable to rotate the adjustment options.
ATR RP
DIM
CCT
100%
5600K
CTRL1 Remote
Dimming Control x1
Button battery x1 User Manual x1
Size
Weight
Battery
Material
Transmission
Remote Control Distance
φ44.5mm*27.5mm
47.6g（Battery not included）
Button Battery CR2450
Aluminum alloy +ABS
2.4GHz
≈ 15~20m/ 49-66 ft (LOS area)
Warranty Period
Thank you for purchasing COLBOR products.
1. Customers are entitled to free replacement or repair service in
case of quality defect(s) found in the product under normal use
within 30 days upon receipt of the product.
2. Original COLBOR products are entitled to 12-month limited
warranty service. The warranty period begins on the date of
purchase of brand new, unused products by the rst end-user.
Within the warranty period, if product defect or failure is
attributable to material defection or technological problem, the
defective product or defective part will be repaired or replaced
without charge (service and materials fee).
Warranty Exclusions and Limitations
1. Faults resulted from inappropriate use of a product without
following its operation specication
2. Articial damage, e.g. crash, squeeze, scratch, soaking,
exposing to rain or damp
3. Modications to a product by its user or a third party without
prior written consent of COLBOR, e.g. replacement of element or
circuit, label alteration
4. The code on product is inconsistent with that of warranty
Room 2401, 24 / F, South Tower, Lisheng Plaza, No. 68 Huadi
Avenue, Liwan District, Guangzhou, China, 510000
support@colborlight.com
www.colborlight.com
Guangzhou Zhiying Technology Co., Ltd
Specications WARRANTY
Package List
certicate, or the code on the product or warranty certicate is
altered or torn o
5. All consumable accessory attached to a product, like cable,
cover
6. Faults as a result of force majeure, such as re, ood, lightning,
etc.
Warranty Claim Procedure
1. If failure or any problem occurs to your product after purchase,
please contact a local agent for assistance, or you can always
contact COLBOR’s customer service through email.
2. Please retain your sales receipt and warranty certicate as
proof of purchase. If any of these documents is missing, only sales
return or chargeable service will be provided.
3. If the COLBOR product is out of the warranty coverage, the
service and the parts cost will be charged.
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR
RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to
contact us via Email.
Customer Name:
Phone Number:
Email:
Address:
Service Date:
Technician:
Issue:
Sales Date:
Model:
Product Code:
Dealer:
Solved Unsolved Returned(Replaced)
Product
Monochrome temperature lights:
CL60M、CL100XM、CL220M
Bi-color temperature lights:
CL60、CL100X、CL220
RGB full-color lights:
CL60R
Adjustable option
Brightness
Brightness → Color
temperature → Brightness
INT → Color temperature →
Hue → saturation → DIM → INT
＊ When connecting multiple lights, double click the turntable to
unify all product options.
2X
3. Adjust parameters
After selecting the option to adjust, turn the dial adjustment option
parameters. Dial the turntable clockwise to increase the parameter
and counterclockwise to decrease the parameter.
