Side 1/2
PURE version
ROYAL ELECTRIC STANDING DESK
Cougar Electric Standing Desk chooses outstanding lifting columns,
control box and keypad with exceptional quality construction. With
cable management attached to preserve you the tidy desk. We
integrate all your needs into this desk.
●
Read and understand this manual before attempting to install or operate.
●
●
Do not sit or stand on the desk. Do not crawl or lie under the desk.
●
Do not place any objects taller than 20” underneath the desk.
●
Do not open any of the components – lifting columns, control box, or controller. There is a
risk of electric shock.
●
The desk must be INITIALIZED before first use.
CAUTION
Make sure no obstacles are in the desk’s path. Make sure the desk top is not touching any walls.
USE & LIABILITY
This sit-to-stand adjustable desk has electric motors and is designed for use in an indoor environment
and dry work areas only. The desk height is adjustable so that it can be positioned at the most suitable
height. Any other use is at user’s risk. Under no circumstances does the manufacturer accept warranty
claims or liability claims for damages caused from improper use or handling of the desk.
CAUTION, USE & ABI TY LI LI
SPECIFICATION
PARTS & HARDWARE LIST FEATURES
TOOLS REQUIRED
Hex Wrench 5mm Hex Wrench 8mm
2
1
x1Desk Top
PARTS / COMPONENT LIST
1
x2Lifting Column
2
x2Foot
3
x1Control Box
4
x10
M10x15mm Hexagon Screw
x10
M6x16mm Hexagon Screw
HARDWARE LIST
A
B
＊Listed qty included 2 extra screws in the package as spare parts
3
3
2
4
ASSEMBLY INSTRUCTIONS
BEFORE YOU BEGIN
1. Lay out all components and hardware to ensure that you have everything listed.
2. The desk weighs over 100 lbs. Two people are needed to turn or move desk top and some components.
When turning or moving the assembled desk, grab it by Lifting column (not the desk top).
3. Assemble on the soft and non-abrasive surface to avoid scratch or damage to the desk top.
Product Name
Preassembled Desk Frame
Desk Dimension
Height Range
Travel Speed
Noise Level
Lifting Capacity
Input
Quality Certifications
Desktop Chemical Test
Electronic Devices Safety Certifications
COUGAR ROYAL ELECTRIC STANDING DESK PURE version
2 stage columns and dual motors desk frame
59”x31”x0.8” or 47”x31”x0.8”
27”- 47”(without desktop) / 28”- 48”(with desktop)
1.57”/second
≦50 decibels during motion
220 Ib
100-240VAC, 50/60Hz
ANSI/BIFMA X5.5-2014 Durability Certification, CE Certification
Meet RoHS, SGS & PROP 65 compliant
Lifting Column, Control Box – UL certification
ENGLISH
●
Premium Stylish Desktop
●
Dual Motor Desk for Extra Weight Capacity, Smooth Lifting and Reliability
●
Superior Knob Control Memory Keypad
●
World-Class Stability Frames
●
Convenient Cable Management Tool
РУССКИЙ
●
Стильный рабочий стол премиум-класса
●
Двухмоторный стол для большего веса, плавного хода и надежности
●
Первоклассная панель управления памятью высот
●
Устойчивая основа отменного качества
●
Удобный механизм укладки кабелей
●
Escritorio elegante de primera calidad
●
Teclado de memoria superior controlado por perilla
●
Marcos de estabilidad de clase mundial
●
Cómodas herramientas de gestión de cableado
●
Escritorio de motor dual para una capacidad de peso extra, elevación suave,
segura y fiable
ESPAÑOL
●
Mesa ergonômica e confortável
●
Avançados botões de controle com apenas 1 toque
●
Estrutura de mesa estável de classe mundial
●
Design conveniente de gerenciamento de cabos
●
Elevação confiável e estável com acionamento por motor duplo
PORTUGUÊS
●
舒适的人体工学桌版
●
稳定可靠的双马达驱动升降系统
●
高级拨杆式一键到位控制器
●
世界一流的稳定性桌架
●
便利收纳的理线设计
中 文
Left Right
Height Controller Cable
Motor Cable
Power Cable
x8
M6x16mm hexagon screw
A
x8
M10x15mm hexagon screw
B
Be aware of your hands
STEP 1
Insert the lifting column so that the back of the lifting column and the back of the crossbar
end are flush. Use Hex wrench 5mm to tighten with 4pcs of screw A (M6x16mm) screws
on each side.
STEP 2
Use 8mm Hex wrench to secure foot to lifting column with four screw B (M10x15mm)
on each side.
STEP 3
1. Connect height controller cable to the right plug on control box.
2. Connect motor cables to control box. Motor cables can be connected interchangeably
to either port.
3. Plug power cable to the left plug on control box.
4. Then put back the sheet metal and make sure well screwed with four screws as original
condition.
