CAENIB

Introduction

The Crestron



CAENIB Series automation enclosures are

designed to house Crestron's CLXI-Series lighting control

modules with optional load- side circuit breakers and a

PAC2 or PAC2M control system. CAENIB enclosures are

available in an assortment of sizes, suitable for surface or

flush wall-mount installation. Each model has been

engineered to provide a clean and manageable installation

with abundant provisions for wire termination and

electrical knockouts.

NOTE: The PAC2 occupies two module spaces in a

double-wide enclosure and one module space in a

single- wide.

NOTE: Four keyholes are located within the enclosure

and should be used if surface mounting.

CAENIB Overall Dimensions (Front and Side Views)

H1 H3

Functional Summary

Specifications

DIMENSIONS 7x2 7x1 4x2 4x1 2x1

(mm (in))

1575

(62)

1575

(62)

987

(38 7/8)

987

(38 7/8)

596

(23 1/2)

(mm (in))

(2 11/16)

(2 1/8)

(mm (in))

1422

(56)

1422

(56)

835

(32 7/8)

863

(34)

473

(18 5/8)

(mm (in))

673

(26 1/2)

390

(15 3/8)

673

(26 1/2)

390

(15 3/8)

390

(15 3/8)

(mm (in))

647

(25 1/2)

365

(14 3/8)

647

(25 1/2)

365

(14 3/8)

365

(14 3/8)

(mm (in))

(2 1/2)

(1 3/4)

(2 1/2)

(1 3/4)

(mm (in))

520

(20 1/2)

276

(10 7/8)

520

(20 1/2)

276

(10 7/8)

276

(10 7/8)

(mm (in))

520

(20 1/2)

250

(9 7/8)

520

(20 1/2)

250

(9 7/8)

250

(9 7/8)

(mm (in))

(2 1/2)

(2 3/4)

(2 1/2)

(2 3/4)

(mm (in))

104

(4 1/8)

104

(4 1/8)

104

(4 1/8)

104

(4 )1/8

104

(4 1/8)

Cover

Thickness

(1/16)

( )1/16

(1/16)

( )1/16

Cover Height

(mm (in))

1593

(62 3/4)

1593

(62 3/4)

1006

(39 5/8)

1006

(39 5/8)

615

(24 1/4)

Cover Width

(mm (in))

692

(27 1/4)

409

(16 1/8)

692

(27 1/4)

409

(16 )1/8

409

(16 1/8)

Included Cover

Plates

6 3 4 2 1

Weight (empty)

(kg (lb))

29.5

(65)

19.5

(43)

(44)

13.2

(29)

8.6

(19)

Max. Weight

(filled) (kg (lb))

90.9

(200)

45.5

(100)

45.5

(100)

(55)

14.1

(31)

1. The lower keyholes are not symmetrically spaced within

single- wide enclosures.

2. Additional cover plates are available from Crestron.

3. Weight (empty) is the weight of an empty enclosure with a cover.

• Houses Crestron lighting modules, terminal

blocks, professional automation computer, and

third-party products with or without Crestron

u mniversal ounting p lates

• Flush or surface mounted installation

• Ventilated cover for convection cooling of

modules

• Conveniently located electrical knockouts for

both high voltage and Class 2 wiring

•

16- o gauge h t dipped galvanized steel

Crestron Electronics, Inc. Installation Guide – DOC. 6562A

15 Volvo Drive Rockleigh, NJ 07647 (2017317)

Tel: 888.CRESTRON 06.14

Fax: 201.767.7576 Specifications subject to

www.crestron.com change without notice.

Automation Enclosures – International Versions, 230 V Crestron CAENIB

Regulatory Compliance Conformité Reglementaire

This product is Listed to applicable UL Standards Ce produit est homologué selon les normes et les

and requirements by Underwriters Laboratories Inc. exigences UL applicables par Underwriters

Laboratories Inc.

As of the date of manufacture, the CAENIB Series has been tested and found to comply with specifications

for CE marking.

Federal Communications Commission (FCC) Compliance Statement

These devices comply with part 15 of the FCC Rules. Operation is subject to the following conditions:

(1) These devices may not cause harmful interference and (2) these devices must accept any interference

received, including interference that may cause undesired operation.

CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for

compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada (IC) Compliance Statement Industrie Canada (IC) Décl aration de conformité

CAN ICES-3(B)/NMB 3(B)-

2 •

•

•• Automation Enclosures – International Versions, 230 V: CAENIB Installation Guide – DOC. 6562A
