DIN-AP3
DIN Rail 3-Series® Automation Processor
Installation and Operations Guide
Hardware Hookup
Make the necessary connections, and apply power after all connections have been made.
NOTE: When making connections to the DIN-AP3, observe the following points:
• Use Crestron power supplies for Crestron equipment.
• The included cable cannot be extended.
Hardware Connections for the DIN-AP3 (Front View)
Description
The Crestron® DIN-AP3 is a 3-Series Control System® automation processor designed for
DIN rail mounting. Featuring the 3-Series control engine, the DIN-AP3 forms the core of
any modern networked home or commercial building, managing and integrating all the
disparate technologies throughout the facility.
Installation
CAUTION: The DIN-AP3 is for indoor use only. Mount in a well-ventilated area. The
ambient temperature must be 32ºF to 104ºF (0ºC to 40ºC). The relative humidity must be
10% to 90% (noncondensing).
CAUTION: To prevent overheating, do not operate this product in an area that exceeds
the environmental temperature range listed on the product web page. Consider using
forced air ventilation to reduce overheating. Also use consideration if installing in a
closed or multiunit rack assembly, since the operating ambient temperature of the
environment may be greater than the room ambient temperature. Contact with thermal
insulating materials should be avoided on all sides of the unit.
NOTES: Observe the following points:
• When installing the DIN-AP3 in an enclosure, group high-voltage devices separately
from low-voltage devices.
• Install and use the DIN-AP3 in accordance with appropriate electrical codes and
regulations.
• A licensed electrician must install the DIN-AP3.
NOTE: Before using the DIN-AP3, ensure the device is using the latest rmware. Check
for the latest rmware for the DIN-AP3 at www.crestron.com/rmware. Firmware is
loaded onto the device using Crestron Toolbox™ software.
Preparing and Connecting Wires
When making the connections, strip the ends of the wires approximately 7/16 in (11 mm).
Use care to avoid nicking the conductors. Tighten the connector to 5 in-lb
(0.5 to 0.6 N-m). The wire gauge should be 14 to 26 AWG.
Installing the DIN-AP3
The DIN-AP3 should be used in a well-ventilated area. The venting holes should not be
obstructed under any circumstances.
The DIN-AP3 is designed for installation on a DIN rail. Refer to the diagram when installing.
Installing the DIN-AP3
Additional Resources
Visit the product page on the Crestron website (www.crestron.com)
for additional information and the latest rmware updates. Use a QR
reader application on your mobile device to scan the QR image.
I/O (G, 8—1):
To Controllable Devices
From Device Outputs (Contact
Closure or Relay Closure)
RELAY (1—4):
To Controllable
Devices
IR/SERIAL (1—4):
To IRP2 or Serial
Devices
COMPUTER:
To Computer Console
COM (1—2):
To RS-232/422/485
Devices
NET (24 Y Z G):
To Any Cresnet® Network Device
Hardware Connections for the DIN-AP3 (Bottom View)
LAN:
10Base-T/100Base-Tx
Ethernet to LAN
Hardware Connections for the DIN-AP3 (Top View)
Memory:
For SD Card
NOTE: Ensure the unit is properly grounded by connecting the chassis ground lug to an
earth ground (building steel).
NOTE: To prevent overheating, do not operate this product in an area that exceeds the
environmental temperature range stated earlier.
Install the DIN-AP3:
1. Use a at object (e.g., a at-head screwdriver) to pull the DIN rail release downward.
2. Place the top of the DIN-AP3’s rail mount over the top of the DIN rail.
3. Tilt the bottom of the DIN-AP3 toward the DIN rail until it snaps into place
NOTE: When mounting DIN rail products, it may be necessary to use a at-head
screwdriver to pull the DIN rail release tab while snapping the device onto the DIN
rail.
To remove the DIN-AP3 from the DIN rail, use a small, at object (e.g., a at-head
screwdriver) to pull the DIN rail release, and tilt the bottom of the DIN-AP3 away from the
DIN rail.
NOTE: Certain third-party DIN cabinets provide space for an informational label between
each DIN rail row. Crestron’s Engraver software (version 4.0 or later) can generate
appropriate labels for all Crestron DIN rail products.
Congure the Control System
The control system can be congured using Crestron Toolbox or the built-in, web-based
setup tool.
Crestron Toolbox
Use Crestron Toolbox to establish communication and congure the control system. For
details, refer to the Crestron Toolbox help le.
Web-Based Setup Tool
1. Use Crestron Toolbox to set the time zone. For details, refer to the Crestron Toolbox
help le.
2. Use the Internet Explorer® web browser to navigate to http://xxx.xx.xx.xxx/setup
where xxx.xx.xx.xxx is the IP address of the control system. The control system’s
welcome screen is displayed.
NOTE: The web-based setup tool is accessible only from Internet Explorer.
NOTE: If a security warning is displayed, click Install to continue.
3. Click Setup to display the DIN-AP3 setup menu. The DIN-AP3 setup menu displays
the IP address, hostname, and MAC address of the device. It also allows access to
various setup and programming screens.
4. From the DIN-AP3’s setup menu, click the following options to congure the control
system:
• Ethernet Setup congures the DIN-AP3’s Ethernet settings and displays DHCP,
hostname, IP address, subnet mask, default router, domain, and MAC address
settings. In the Ethernet setup menu, there are additional options:
• Click Advanced Settings to specify DNS servers, web server settings, and
SSL settings.
• Click MyCrestron Dynamic DNS to congure the myCrestron.com Dynamic
DNS service.
• Click Ethernet Diagnostics to test the Ethernet communications.
• Click Reboot to reboot the DIN-AP3.
• selects programs to be loaded on startup and controls which Application Setup
program(s) are running.
• congures the COM ports, operates the relays, and Input/Output Control
monitors the Versiports.
• displays information about the connected devices, hardware Diagnostics
conguration, and error logs.
• About displays rmware information.
Click to return to the previous screen.
As of the date of manufacture, the product has been tested and found to comply with specications
for CE marking.
This product is Listed to applicable UL
® Standards and requirements by Underwriters Laboratories
Inc.
CAUTION: Changes or modications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
Crestron Electronics, Inc. Installation & Operations Guide - DOC. 7491C
15 Volvo Drive Rockleigh, NJ 07647 (2035917)
Tel: 888.CRESTRON 01.16
Fax: 201.767.7576 Specications subject to
www.crestron.com change without notice.
If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)
Crestron software, including without limitation, product development software and product operating
system software is licensed to Crestron dealers and Crestron Service Providers (CSPs) under a limited
non-exclusive, non-transferable license pursuant to a separate end-user license agreement. The terms of
this end user license agreement can be found on the Crestron website at
www.crestron.com/legal/software_license_agreement.
The product warranty can be found at www.crestron.com/warranty.
The specic patents that cover Crestron products are listed at patents.crestron.com.
Certain Crestron products contain open source software. For specic information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, 3-Series, 3-Series Control System, Cresnet, and Crestron Toolbox are either
trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other
countries. UL and the UL logo are either trademarks or registered trademarks of Underwriters Laboratories,
Inc. in the United States and/or other countries. Internet Explorer is either a trademark or registered
trademark of Microsoft Corporation in the United States and/or other countries.
Troubleshooting
The following table provides corrective action for possible trouble situations. If further
assistance is required, please contact a Crestron customer service representative.
DIN-AP3 Troubleshooting
Other trademarks, registered trademarks, and trade names may be used in this document to refer to
either the entities claiming the marks and names or their products. Crestron disclaims any
proprietary interest in the marks and names of others. Crestron is not responsible for errors in
typography or photography.
This document was written by the Technical Publications department at Crestron.
©2016 Crestron Electronics, Inc.
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION
The device does not
function.
The device is not
communicating with the
network.
Use Crestron Toolbox to
poll the network. Verify
that the network is
connected to the device.
The device is not receiving
power from a Crestron
power supply.
Use the provided Crestron
power supply. Verify that
the connections are
correct and secure.
The device is not receiving
sufcient power.
Use the Cresnet® Power
Calculator to help
calculate how much
power is needed.
The MSG LED illuminates. There is a hardware or
software failure.
Verify that the hardware
conguration matches the
software conguration.
Use Crestron Toolbox to
display the error log.
The compilation errors
RLCMCVT166 and
RLCMCVT177 appear.
A poor analog versus
serial signal denition
exists in the SIMPL
Windows program.
Conrm that the signal
denition is properly
dened in the program.
The system locks up. There are various causes. Hold down the SW-R
button on the front panel
to bypass the program
and communicate directly
with the processor. Refer
to “Troubleshooting
Communications” in the
Crestron 3-Series Control
System Reference Guide
(Doc. 7150) at
www.crestron.com/
manuals for more details.
A Cresnet device does not
respond.
The device is not wired
correctly.
Verify that the Cresnet
wiring is correct and
secure.
An improper NET ID was
used.
Verify that the device ID
matches the NET ID in the
program.
There is a loss of
functionality due to
electrostatic discharge.
The device is improperly
grounded.
Check that all of the
ground connections have
been properly made.
The A/V system device
does not respond.
The IRP2 or SERIAL port
is not placed properly.
Verify the placement of
the IRP2 (hold phosphor
card under IRP2 while
pressing button), and
tighten serial cables.
The wrong IR/SERIAL port
was used.
Verify that the proper
IR/SERIAL port is dened.
The serial cable is not
wired correctly.
Verify that the serial cable
is wired correctly for
RS-232, -422, -485.
The device is not receiving
sufcient power.
Use the Cresnet Power
Calculator to help
calculate how much
power is needed.

Produkt Specifikationer

Mærke: Crestron
Kategori: Ikke kategoriseret
Model: DIN-AP3

Har du brug for hjælp?

Hvis du har brug for hjælp til Crestron DIN-AP3 stil et spørgsmål nedenfor, og andre brugere vil svare dig


Ikke kategoriseret Crestron Manualer

Crestron

Crestron Green Light GL-EXP-SW-CN Manual

10 September 2025
Crestron

Crestron FT2A-PWR-IT-1-BASIC Manual

10 September 2025
Crestron

Crestron FT2A-PWR-AU-2 Manual

10 September 2025
Crestron

Crestron FT2A-PWR-UK-2 Manual

10 September 2025
Crestron

Crestron Green Light GLXX-2DIM8 Manual

10 September 2025
Crestron

Crestron FT2A-PWR-EU-1-BASIC Manual

10 September 2025
Crestron

Crestron FT2A-PWR-UN-1-BASIC Manual

9 September 2025
Crestron

Crestron FT2A-PWR-US-3 Manual

9 September 2025
Crestron

Crestron FT2A-PWR-SW-1-BASIC Manual

9 September 2025
Crestron

Crestron FT2A-PWR-US-1-BASIC Manual

9 September 2025

Ikke kategoriseret Manualer

Nyeste Ikke kategoriseret Manualer

Elektrobock

Elektrobock PT44 Manual

14 September 2025
BSS Audio

BSS Audio FDS-366T Manual

14 September 2025
Systemair

Systemair Airline R-114 Manual

14 September 2025
IFM

IFM SU2031 Manual

14 September 2025
Morel

Morel Tempo Ultra Integra 502 Manual

14 September 2025
IMC Networks

IMC Networks 232CL9R Manual

14 September 2025
Varta

Varta Speed Charger 57955 Manual

14 September 2025
Melissa & Doug

Melissa & Doug 9336 Manual

14 September 2025
Opus

Opus dataPREDATOR Manual

13 September 2025
Varta

Varta Wireless Power Bank 20000 57909 Manual

13 September 2025
