VECTOR SUBS18
Vector™ 18” Performance Subwoofer
crestron.com | 800.237.2041
>A professional performance subwoofer for use with Vector™
Performance Loudspeakers
>High-power, long-excursion 18” (457 mm) low-frequency
transducer
>Compact vented enclosure tuned for maximum low-frequency
output
>Delivers superior performance in combination with an Avia™ DSP
>Precisely tuned for articulate, impactful deep bass response
>Ruggedly constructed for maximum reliability
>Concealed M10 mounting points
>Forged shoulder eyebolts available separately
>Neutrik® speakON® input and pass-through connections
The Vector™ SUBS18 is a direct-radiating, vented subwoofer featuring a
single high-power, long-excursion 18” (457 mm) transducer. It is designed
to provide extended low frequency support for use with CS and CD series
Vector Performance Loudspeakers, and is capable of producing articulate
and impactful deep bass response for all types of installed music and
multimedia applications.
The Vector SUBS18 requires use with a Crestron Avia
™ DSP to ensure
rated performance and reliable operation. Its enclosure is optimally
tuned to provide maximum low frequency output in a compact package,
facilitating placement in tight spaces. Concealed M10 mounting points are
included to allow for suspended installation using forged shoulder eyebolts
(sold separately).
SPECIFICATIONS
Performance
Transducer: 18 inch (457 mm) woofer with 4 inch (102 mm) voice coil
and ceramic magnet
Beamwidth: Spherical
Impedance: 8 Ohms nominal
Frequency Range: 25 to 141 Hz (+3/-10 dB)
Power Handling: 1200 Watts based on the AES power handling of the
transducer
Nominal Sensitivity: 100 dB half space, 94 dB whole space, at 1W/1m
using band limited pink noise without processing
Nominal Maximum SPL: Half space: 136 dB peak, 130 dB continuous;
Whole space: 130 dB peak, 124 dB continuous;
Measured at 1200W/1m without processing
Equalized Sensitivity: 98 dB half space, 92 dB whole space, at 1W/1m
using an EIA-426-B signal with processing
Equalized Maximum SPL: Half space: 135 dB peak, 129 dB continuous;
Whole space: 129 dB peak, 123 dB continuous;
Measured at 1200W/1m with processing
Processing & Amplification
Digital Signal Processing: Requires processing using one output
channel of a Crestron Avia DSP, settings provided via model-specific
“Speaker Profiles” in the Avia Audio Tool software (SW-AAT)
Amplification: Requires a single channel of amplification
Recommended Amplifier Power: 1200 to 1800 Watts at 8 Ohms
Connections
Input: (2) Neutrik NL4 speakON 4-pole chassis connectors;
Pins 1 +/–: Speaker input and pass-through;
Pins 2 +/–: Pass-through only
Environmental
For indoor use only
Construction
Enclosure: Void-free, exterior grade Baltic Birch plywood; black
painted finish
Grille: Steel, black powder coat finish
Suspension: (16) M10 eyebolt angle points (eyebolts sold separately)
Dimensions
Height: 29.75 in (756 mm)
Width: 24.55 in (624 mm)
Depth: 19.62 in (498 mm)
VECTOR SUBS18 Vector
™
18” Performance Subwoofer
crestron.com | 800.237.2041
Weight
92.0 lb (41.7 kg)
MODELS & ACCESSORIES
Available Models
VECTOR SUBS18: Vector™ 18” Performance Subwoofer
Available Accessories
VECTOR EB10: M10 Forged Shoulder Eyebolt
VECTOR CONN2: Neutrik® NL2 speakON® 2-Pole Cable Connector
VECTOR CONN4: Neutrik® NL4 speakON® 4-Pole Cable Connector
DSP Series: Avia™ Digital Signal Processors
Notes:
This product may be purchased from an authorized Crestron dealer. To find a dealer, please
contact the Crestron sales representative for your area. A list of sales representatives is available
online at www.crestron.com/salesreps or by calling 800-237-2041.
The specific patents that cover Crestron products are listed online at: .patents.crestron.com
Certain Crestron products contain open source software. For specific information, please visit
www.crestron.com/opensource.
Crestron, the Crestron logo, Avia, and Vector are either trademarks or registered trademarks of
Crestron Electronics, Inc. in the United States and/or other countries. Neutrik and speakON are
either trademarks or registered trademarks of Neutrik AG in the United States and/or other
countries. Other trademarks, registered trademarks, and trade names may be used in this
document to refer to either the entities claiming the marks and names or their products. Crestron
disclaims any proprietary interest in the marks and names of others. Crestron is not responsible
for errors in typography or photography. Specifications are subject to change without notice.
©2017 Crestron Electronics, Inc.
Axial Sensitivity (dB SPL, 1W/1m)
Plotted against frequency for a 1 watt swept sine wave, referenced to 1 m without processing
Axial Processed Response (dB)
The axial magnitude response with processing
Impedance (Ohms)
