AMP-CH5

OEM Amplier Replacement Interface for

Chrysler, Dodge, Jeep & RAM Vehicles with Uconnect Systems

INTERFACING SOLUTIONS

- Retains U-Connect and navigaon prompts.

- Retains Bluetooth handsfree mode.

- Allows adjustments for Balancing/Fading, Bass, Mid and Treble frequencies.

- Retains OEM radio EQ controls.

- Adjustable bass frequency and level. Includes an under dash mount encoder/bass knob.

- Provides 4 channel Front/Rear outputs plus non-fading subwoofer output.

- Remote output to turn on aermarket amplier.

- Includes an OEM amplier Bypass harness. No cung of factory wires.

PRODUCT FEATURES:

PARTS INCLUDED:

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

1 of 4 rev.092519

PRODUCT OVERVIEW:

The AMP-CH5 allows for an improvement in audio quality in vehicles equipped with data-bus controlled amplied

sound systems by upgrading to an aermarket mul-channel amplier while retaining the factory radio. The

AMP-CH5 provides balance, fader, bass, mid and treble frequency adjustments as well as a non-fading subwoofer

output for opmum sound staging.

NOTE:

AMP-CH5 Module AMP-CH5 Harness

OEM Amp Bypass Harness AMP-CH5 Encoder/Bass Knob

Audio from the factory backup sensors is not retained.

1. Carefully remove the trim bezel

around the radio and instrument

cluster. Use a plasc pry tool and go all

the way around the trim to pop up the

clips.

2. Remove the 4 screws holding

the screen.

3. Unplug the 52-pin connector

behind the screen.

6. Find a suitable locaon to mount

the aermarket amplier(s). You

will need to run the following to the

aermarket amplier:

1) Power wires from the baery

2) An amp turn-on wire and RCA

cables from the AMP-CH5 module.

3) Speaker wires from the OEM

amplier locaon. OEM amplier

locaon can vary by vehicle. On

sedans and trucks, it is usually

located on the le boom side of

the dashboard. On SUVs in the cargo

area. Make sure you have enough

length wires and RCA cables.

4. Plug the 52-pin connector to the

mang connector on the AMP-CH5

T-harness.

5. Plug the other end of the

AMP-CH5 T-harness to the OEM

screen.

7. On a 2017 Dodge Charger, the OEM

amplier is at the le boom side

of the dashboard. Remove the panel

above the pedals by removing the

panel clips.

8. Locate the OEM amplier and

unplug the connectors.

9. Connect the speakers wires from

the aermarket amplier to the Amp

Bypass harness included in the kit.

Mate the connectors into the OEM

amplier harness connectors.

INTERFACING SOLUTIONS

AMP-CH5

OEM Amplier Replacement Interface for

Chrysler, Dodge, Jeep & RAM Vehicles with Uconnect Systems

INSTALLATION INSTRUCTIONS:

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

2 of 4 rev.092519
