- Retains factory features in select GM LAN 29 Bit vehicles while func oning with an rmarket

radio.

- Pre-programmed to retain factory Steering Wheel Controls.

- Retains OnStar, factory Rear view camera and chime fun ons.

- Adds Forced Rear view and Front view camera while in mo

on using the factory side mirror

controls.

- Supports Bose, non-Bose and Y-91 audio systems.

EIA color coded wiring for easy installa on.

Includes Double DIN Dash Kit

1. The Front and Rear fading are not retained on Y-91 Bose System.

2. Chime includes: seat belt, check engine, key in igni

on, low fuel, low oil and lights on.

Video Harness

SETTING THE AFTERMARKET RADIO BRAND

With the key in the o pos on, set the DIP switches to the corresponding a rmarket radio se ng.

3.5MM SWC CABLE

Plug in the 4-Pin SWC cable to the 4-pin connector plug on the module.

NOTE: Cap or insulate the 3.5mm plug, the Blue/Yellow or Green wires if not being used.

SWC 3.5MM PLUG ADAPTER:

RAD IO REP LACEMENT

SWC RETEN TION

INTERFACING SOLUTIONS

DKGM-16W

Dash Kit oidaR noitagivaN htiw SKCURT & s’VUS tiB 92 NAL MG rof

PRODUCT FEATURES:

NOTES:

DIP SWITCH SETTINGS:

DKGM-16W Module

DKGM-16W HarnessDouble Din Dash Kit

Crux Interfacing Solutions • Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

1 of 7

Radio Replacement with OnStar Retention, SWC Retention, & Double DIN

SWC Cable &

Antenna Adaptor

rev.03282023

RSE Retention

Harness

Provides Factory Rear Seat Entertainment Activation with RSE Cable #CRUX2444A

RAD IO REP LACEMENT

SWC RETEN TION

INTERFACING SOLUTIONS

DKGM-16W

Dash Kit oidaR noitagivaN htiw SKCURT & s’VUS tiB 92 NAL MG rof

SELECTING THE AUDIO SYSTEM:

BOSE

Conne on

Non-BOSE

Conne on

2 / 6

If the vehicle is equipped with a Bose system, the DKGM-16W has a built in

DKGM-16W module. The module is also labeled “Bose” and “Non Bose” to

avoid confusion. (see picture below)

If the vehicle is not equipped with a Bose system, plug in the male

module.

Crux Interfacing Solutions • Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

2 of 7

INSTALLATION DIAGRAM:

Radio Replacement with OnStar Retention, SWC Retention, & Double DIN

rev.03282023

AFTERMARKET

RADIO

Reverse Gear Red/White

Parking Brake Yellow/Black

Illuminaon (+) Orange

+12V Constant Yellow

+12V ACC Red

Ground Black

Right Front (+) Gray

Right Front (-) Gray/Black

Le Front (+) White

Le Front (-) White/Black

Right Rear (+) Violet

Right Rear (-) Violet/Black

Le Rear (+) Green

Le Rear (-) Green/Black

TO FACTORY

HARNESS

24-Pin

Connector

8-Pin

Connector

BOSE NON

BOSE

10-Pin

Connector

SWC DIP SWC CAM

1 2 3 4

Video Out

Front Camera

Rear Camera

To OEM Camera

Harness

Gray 20-Pin

Connector

VIDEO HARNESS

Chime Volume

Adjustment

1 2 3

VR Activation

for OnStar (set DIP#1 to ON)

44-PIN

CONNECTOR

Vehicle Speed Sense

(Green/White)

4-Pin

Connector

Cap or insulate if

not being used

3.5MM SWC CABLE

Plug in the 3.5MM SWC cable to the 4-pin port

on the module. See “DIP SWITCH SETTINGS” section.

LIN BUS (Green/Black)

JVC/Kenwood (Blue / Yellow)

Insulate if not

being used

TROUBLESHOOTING

LED

LIGHT

LED MODULE FEEDBACK

Solid blue

Flashing blue

Solid red Module providing 12V ACC

CAN not recognized

CAN recognized

12V ACC OFFRed off
