Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

PRODUCT FEATURES:

- Retains factory backup camera.

2. This interface does not retain the factory Bluetooth or Sirius Satellite Radio.

PARTS INCLUDED:

SWRVW-52B Module SWRVW-52B Harness SWC Cables

rev.072322

1 of 4

NOTES:

INSTALLATION DIAGRAM:

AFTERMARKET

RADIO

+12V Constant Yellow

+12V A

Red

ound Black

Illumin

a

on (+) O

range

Vehicle Speed Sense Purple/White

Reverse Gear Signal Red/White

Right Fron

t (+) G

ray

Right Front (-) Gray/Black

Le Fron

t (+) Whi

Le Front (-) White/Black

Right Rear (+) Purple

Rig

ht Rear (-) Purple/Black

Le R

ear (+) G

reen

Le Rear (-) Green/Black

Backup Camera Input Yellow RCA

TO FACTORY

HARNESS

12-Pin

Connector

1 2 3

4-Pin

Connector

3.5MM SWC CABLES (Option A or B)

Use the proper 3.5MM to 4-Pin cable for your radio.

Plug in the selected 3.5MM SWC cable to the 4-pin

port on the module. See “DIP SWITCH SETTINGS” section.

mini USB

Not Used

Option A:

Option B:

Cap or insulate if

not being used

BLUE / YELLOW FOR JVC & KENWOOD

AUDIO

SEEK

RADIO

MEDIA

VOLUME

OPEN

Backup camera input

To aftermarket

radio SWC wire

or 3.5mm port

DKVW-52B

Radio Replacement with Steering Wheel Control Retention

INTERFACING SOLUTIONS

and Dash Kit for Select VW Vehicles

- Includes Single DIN/ISO with pocket or Double DIN Dash Kit.

Single DIN/ISO with pocket

or Double DIN Dash Kit

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

rev.072322

SETTING THE AFTERMARKET RADIO BRAND

corresponding radio listed below.

2 of 4

VOLKSWAGEN

2016 – 2018 Beetle

2016 – 2018 Passat

2016 – 2017 Tiguan

VEHICLE APPLICATIONS:

2017 Beetle Radio

RADIO BRAND: DIP#: 1 2 3

Atoto, Dual, Fahrenheit, Jensen

Pioneer, Power Acoustik, Soundstream

Alpine

Clarion

Kenwood

JVC

Boss, Old Sony

New Sony

OFF ON ON

OFF OFF OFF

ON ON OFF

ON ON ON

ON OFF ON

ON OFF OFF

OFF ON OFF

SWC MODULE

DIP SWITCH

1 2 3

NOTE:

check the aftermarket radio’s manual to see if the SWC buttons need to be pro ammed.gr

4-PIN SWC CABLE

OPTION A is used for ALPINE, CLARION. For JVC and KENWOOD use the Blue/Yellow wire.

OPTION B is used for ATOTO, BLAUPUNKT, BOSS, DUAL, FARENHEIT, JENSEN, POWER ACOUSTIK,

NOTE: Cap or insulate the 3.5mm plug or Blue/Yellow wire if not being used.

RED to SWC Key 1

WHITE to SWC Key 2

SHIELD to SWC Ground

SWC wires as follows:

Note that there are some radios that only have SWC1 and SWC2, in this case “shield” does not need to be connected.

DKVW-52B

Radio Replacement with Steering Wheel Control Retention

INTERFACING SOLUTIONS

and Dash Kit for Select VW Vehicles

Produkt Specifikationer

Mærke:	CRUX
Kategori:	Ikke kategoriseret
Model:	DKVW-52B
