Side 1/3

RVCCH-75C

Rear View Integration Interface with VIM

for CHRYSLER, DODGE & JEEP

INTERFACING SOLUTIONS

Sightline

Multi View Integration

Crux Interfacing Solutions • Chatsworth, California

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

rev.020520

1 of 3

• Acvates Uconnect Touchscreen Radio for enabling Video features

• Aermarket Rear-view Camera included

• Automacally switches to Rear-view when car is in Reverse mode

• Forced reverse camera view feature

• VIM funcon

• Plug & Play Installaon

PRODUCT FEATURES:

PARTS INCLUDED:

RVCCH-75C Module RVCCH-75C Harness CCH-01G Camera

INSTALLATION DIAGRAM:

WHITE Wire

Parking Guideline

To Radio

OEM Radio

Harness

DIP

SWITCH

LED*

*LED RED = Power ON Status

LED BLUE = Data Bus ON Status

RVC Video

Signal Input

RED Wire

Push in Connectors

all the way

Line up Arrows

Regulator

20 Ft. Coax Cable

RED Wire

Tape O

(Not Used)

BLACK

Wire

BLACK

(Ground)

8-Pin Molex

Represents Solder Joint

Connect RCAs and secure

with tape all around

WHITE Wire

(Camera Power Output

+12V 250mA)

OR*

*Connect BLACK (ground) wire to a source ground and not

chassis ground (i.e. ground wire on reverse light)

If video noise is present, we recommend connecting the

ground wire to the BLACK ground wire on the RVCCH-75C harness.

Source Ground

GREEN Wire

For Non Permanent

VIM function

Crux Interfacing Solutions • Chatsworth, California

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

rev.020520

2 of 3

INTERFACING SOLUTIONS

Sightline

Multi View Integration

DIP SWITCH SETTINGS:

INSTALLATION INSTRUCTIONS:

INSTALLING THE CDR-02 CAMERA AND CABLE

1. Remove the rear panel lip.

2. Drill a 5/8 inch size hole in the available locaon.

3. Fish the wires thought the drilled hole and through the pass through into the trunk/cargo area.

4. Route the wires towards the radio and make the power and video connecons. For powering up the camera, use the 12V

OUTPUT (White Wire). (See Wiring Diagram on page 1)

5. Connect the camera ground wire to chassis ground. If video noise is present, we recommend grounding the camera

directly to the BLACK wire on the RVCCH-75C T-harness.

6. Test the camera before re-installing the radio.

CODING THE RADIO FOR A REAR VIEW CAMERA

The radio has to be coded to accept a reverse camera. Please follow the coding procedure below:

1) Turn key o and remove the key from ignion.

2) Open the driver door then close it (make sure all doors, li gate and hood are also closed).

3) Look at the module and wait for LEDs to turn o then disconnect the module.

4) Before plugging back the module, turn all DIP switches to ON then OFF.

5) Set DIP switches 1 (if permanent VIM is desired), 2 and 6 to the ON posion.

6) Reconnect module and wait for the LEDs to turn o.

7) Start up engine and the coding operaon is complete.

8) Put the gear in reverse to test the camera.

FORCED VIEW OF REVERSE CAMERA

The Force RVC is used to view the back-up camera when the vehicle is

not in reverse gear. Allows you to view what is in the back while driving.

To acvate this feature, make sure that DIP 4 is set to ON. Press the center

buon once on the le hand side steering wheel control (located behind the steering wheel).

NOTE: The camera is defaulted to power down aer 10 seconds.

DIP SWITCH FUNCTIONS:

DIP 1 = Video in Moon Acvaon ON / OFF

DIP 2 = Rear View Camera ON / OFF

DIP 3 = Not Used

DIP 4 = Forced RVC ON / OFF

DIP 5 = Defaulted to OFF*

DIP 6 = Defaulted to ON*

RVCCH-75C

Rear View Integration Interface with VIM

for CHRYSLER, DODGE & JEEP

*DIP 5 & 6

If the radio is having turn-on issues, please try the following:

Aempt 1: Set 5 & 6 to ON

Aempt 2: Set 5 to ON and 6 to OFF

Aempt 3: Set 5 to OFF and 6 to ON

1 2 3 4 5 6
