RVCGM-80C
Rear View Integration Interface for Select
GM Vehicles with CUE, Intellilink and MyLink Systems
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
Crux Interfacing Solutions • 6860 Canby Ave., Suite 116, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.082718
1 of 8
- Automacally switches to rear-view when vehicle is put in reverse gear.
- Provides reverse camera input.
- Adds 3 Audio/Video inputs.
- Plug and play installaon.
PRODUCT FEATURES:
PARTS INCLUDED:
RVCGM-80C
Module
Remote Control Power Harness
IR Extension Cable LVDS Cable A/V Cable
Camera Power Harness Push Buon Switch
Crux Interfacing Solutions • 6860 Canby Ave., Suite 116, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.082718
2 of 8
R
INTERFACING SOLUTIONS
Sightline
Multi View Integration
RVCGM-80C
Rear View Integration Interface for Select
GM Vehicles with CUE, Intellilink and MyLink Systems
INSTALLATION DIAGRAM:
AV1
AV2
LVDS
Output
AV3
AV OUT
+12V ACC
GROUND
Fuse Box
Connect to Blue
Mini USB Plug from
HMI Module
Plug to HMI
Module
RGB CABLE
IR REMOTE CABLE
PUSH BUTTON SWITCH
CAMERA POWER
+12V GROUND
DIP SWITCHES
Sig tli e
REAR-VIEW INTEGRATION
RVCGM-80C
24-PIN
POWER PLUGSTATUS LED
24-Pin
Audio/Video
IN/OUT
GM-80C LVDS
T-HARNESS
