INTERFACING SOLUTIONS
RVCPR-66
REAR-VIEW INTEGRATION INTERFACE
FOR PORSCHE VEHICLES 2008-UP
w/ PCM3.1 & PCM 3.0
PORSCHE
2013 - 2015 911
2014 - 2015 Boxster
2008 - 2015 Cayenne
2014 - 2015 Cayman
2010 - 2015 Panamera
Disclaimer: Depending on the HW version of your PCM system, this product may not support some
versions. Please contact us for more information.
Internal DVD player will not be
able to be watched while in
motion.
Contact Tech Support for more
information.
PARTS INCLUDED
(1) PR-66 CAN Interface Module
(1) PR-66 40-Pin T-Harness
(1) C-02 Camera
(1) 15ft Extension
(1) Instruction Sheet
SAFETY PRECAUTIONS
1. Please read through the entire instruction manual before starting any of the installation procedures.
2. We recommend disconnecting the negative side of the battery until ready to code the vehicle.
3. Do not install any of the main modules near any major components or near the HVAC system,
as placing items near the HVAC may cause damage or overheating to the vehicle or interface.
4. We recommend not disconnecting any of the air bag connections behind the dash panels.
5. This product is under Crux’s 1 year manufacturer’s warranty. Warranty may be voided in the case where
the device shows proof of being opened or improper extreme force.
TECH SERVICES
All our products are manufactured under strict quality control. Each device is being tested before shipment. If nevertheless do occur problems or if
you have technical questions, contact us directly:
Crux Interfacing Solutions Tech Support
1 (855) 822-1348 (Mon - Fri - 9:00 AM - 5:00 PM) Time
www.cruxinterfacing.comRev. 032815 1
2015 911 GT3
2014 - APPLICATION NOTES:
ONLY FOR VEHICLES WITHOUT
FACTORY REAR-VIEW CAMERA
WORKS FOR:
PCM 3.1 NAVIGATION RADIOS
PCM 3.0 NAVIGATION RADIOS
(Cayenne Only)
(from Software Version 4.xx ONLY)
(from Software Version 4.xx ONLY)
(from Software Version 4.xx ONLY)
INTERFA LUT IO NSCING SO
RVCPR-66
REAR-VIEW INTEGRATION INTERFACE
FOR PORSCHE VEHICLES 2008-UP
w/ PCM3.1 & PCM 3.0
INSTALLATI OVERVIEWON
www. u n mcr xinterfaci g.coRev. 0 15 2328
ON
1 2 3 4 5 6
TO FACTORY
HARNESS
40-PIN
(male plug)
40-PIN
(female plug)
8-PIN
(male plug)
GREEN/ REVERSE WIRE
WHITE/ ALTERNATIVE CODING
CAN
INTERFACE
CAMERA
(INCLUDED)
YELLOW / VIDEO SIGNALCAMERA INPUT
TAP BLACK/ CAMERA GROUND
4 5 6
ON
1 2 3
DIP 1 = OFF
2 = ON
3
4
5
DIP 6 = ON
OFF
NO
VIDEO
IN-MOTION
CAN
INTERFACE
DI TCH RVIEWP SWI ES OVE
Ma e to et dip itc ber k sure s sw h num 6
to “ON positio ” n.
Fo e featu illr h t RVC re, you w only
need to set dip switch “2” to ON.
NO :TE ABOUT THE EENGR WIRE
The wire prov 2 e GR N EE ides 1 v when th
RE s EvVE E iRS gear en (gaged en nwith the ignitio
OFF, eh ’the v icle s S CA BUN- is s etill active). Th
GREE wir w v e N e ill be deacti ated when the vehicl
i n I and as s n s placed i to DR VE h a peed higher tha
10mph.
CA TEME RA NO :
The A V W A res nRE R- IE C MERA will be p ent whe
the ron n .elect ic BRAKE is dise gaged
