Side 1/6
- Retains factory features in select GM LAN 29 Bit vehicles while func oning with an rmarket  ae
radio.
- Pre-programmed to retain factory Steering Wheel Controls.
- Retains OnStar, factory Rear view camera and chime funcons.
- Adds Forced Rear view and Front view camera while in mo on using the factory side mirror controls.
- Su orts Bose, non-Bose a Y-91 audio systems. pp nd
- EIA color coded wiring for easy installa on.
1. The Front and Rear fading are not retained on Y- Bose System. 91
2. Chime includes: seat belt, check e ine, key in igni on, low fuel, low oil and lights on. ng
SOOGM-16W Mo le du
SOOGM-16W arness H
Video Harness
Antenna Adaptor
SWC Cable
SETTING THE AFTERMARKET R IO BRAND AD
With the key in the o pos on, set the DIP switches to the correspo ing a rmarket radio se ng. ff i nd e 
3.5 SWC CABLE MM
Plug in the 4-Pin SWC cable to the 4-pin c ector plug the module. onn on
NOTE: C or insulate the 3.5mm plug, the Blue/Yellow or Gr n wires if not being used.ap ee
SWC 3.5MM PLUG ADAPTER:
- Supports Rear Entertainment System with special order harness # A2444
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
1 of 6 rev.03282023
RSE Retention
Harness
If the vehicle is equipped with a Bose system, the SOOGM-16W has a
built-in Bose adaptor that allows the proper audio in t gain from pu
the a ermarket radio to the Bose ampli . To use this feature, plug  fier
in the male 8-pin co ec r on th harness to the GRAY female 8-pin nn to e
co ector on the SOOGM-16W mo le. The mo le is also labeled nn du du
“Bose” and “Non Bose” to avoid confusion. (see picture below)
If the vehicle is NOT equipped with a Bose system, pl in the male ug
8-pin co ector to the BLAnn CK female 8-pin on the SOOGM- W 16
module.
Co e on nn c
Non-BOSE
Co e on nn c
AFTERMARKET
RADIO
Reverse Gear Red/White
Parking Brake Yellow/Black
Illuminaon (+) Orange
+12V Constant Yellow
+12V ACC Red
Ground Black
Right Front (+) Gray
Right Front (-) Gray/Black
Le Front (+) White
Le Front (-) White/Black
Right Rear (+) Violet
Right Rear (-) Violet/Black
Le Rear (+) Green
Le Rear (-) Green/Black
TO FACTORY
HARNESS
24-Pin
Connector
8-Pin
Connector
BOSE NON
BOSE
10-Pin
Connector SWC DIP SWC CAM
1 2 3 4
ON
Video Out
Front Camera
Rear Camera
To OEM Camera
Harness
Gray 20-Pin
Connector VIDEO HARNESS
Chime Volume
Adjustment
1 2 3
ON VR Activation
for OnStar (set DIP#1 to ON)
44-PIN
CONNECTOR
Vehicle Speed Sense
(Green/White)
4-Pin
Connector
Cap or insulate if
not being used
3.5MM SWC CABLE
Plug in the 3.5MM SWC cable to the 4-pin port
on the module. See “DIP SWITCH SETTINGS” section.
LIN BUS (Green/Black)
JVC/Kenwood (Blue / Yellow) Insulate if not
being used
TROUBLESHOOTING
LED
LIGHT LED MODULE FEEDBACK
Solid blue
Flashing blue
Solid red Module providing 12V ACC
CAN not recognized
CAN recognized
12V ACC OFFRed off
Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
2 of 6 rev.03282023
