SWRVW-52B

Radio Replacement with Steering Wheel Control and

Factory Backup Camera Retention for Select Volkswagen Vehicles

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

RADI O R EPLACE MENT

SWC RETENTIO N

INTERFACING SOLUTIONS

PRODUCT FEATURES:

- Retains factory features in select Volkswagen vehicles while funconing with an aermarket radio.

- Retains factory Steering Wheel Control funcons.

- Retains factory backup camera.

1. Driver informaon display will show the last informaon that was shown prior to removing the factory radio.

2. This interface does not retain the factory Bluetooth or Sirius Satellite Radio.

3. Not compable with amplied systems.

PARTS INCLUDED:

SWRVW-52B Module SWRVW-52B Harness SWC Cables

rev.072219

1 of 2

NOTES:

INSTALLATION DIAGRAM:

AFTERMARKET

RADIO

+12V Constant Yellow

+12V ACC Red

Ground Black



Vehicle Speed Sense Purple/White



















Backup Camera Input Yellow RCA

TO FACTORY

HARNESS

12-Pin

Connector

1 2 3

4-Pin

Connector

3.5MM SWC CABLES (Option A or B)

Use the proper 3.5MM to 4-Pin cable for your radio.

Plug in the selected 3.5MM SWC cable to the 4-pin

port on the module. See “DIP SWITCH SETTINGS” section.

mini USB

Not Used

Option A:

Option B:

Cap or insulate if

not being used

BLUE / YELLOW FOR JVC & KENWOOD

Insulate with

tape if not

being used

AUDIO

SEEK

RADIO

MEDIA

VOLUME

OPEN

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

RADI O R EPLACE MENT

SWC RETENTIO N

INTERFACING SOLUTIONS

rev.072219

SWRVW-52B

SETTING THE AFTERMARKET RADIO BRAND

This step is done on the SWRVW-52B Module. With the key in the o posion, set the DIP switches to the

corresponding radio listed below.

2 of 2

VOLKSWAGEN

2016 – 2018 Beetle

2015 – 2018 Golf / GTI

2017 – 2018 Golf Alltrack

2015 – 2018 Golf R

2015 – 2017 Golf Sportwagen

2016 – 2018 Jea / GLI

2016 – 2018 Passat

2016 – 2017 Tiguan

VEHICLE APPLICATIONS:

2017 Beetle Radio

RADIO BRAND: DIP#: 1 2 3

Dual, Fahrenheit, Jensen, Pioneer

Power Acoustik, Soundstream

Blaupunkt, Most o-brand Radio

Alpine

Clarion

Kenwood

JVC

Boss, Old Sony

New Sony

OFF ON ON

OFF ON OFF

OFF OFF OFF

ON ON OFF

ON ON ON

ON OFF ON

ON OFF OFF

OFF ON OFF

SWC MODULE

DIP SWITCH

1 2 3

NOTE: For Blaupunkt, Dual, Farenheit, Power Acoustik, Soundstream, and most o-brand radios,

check the aftermarket radio’s manual to see if the SWC buttons need to be programmed.

4-PIN SWC CABLE

Use the proper 3.5MM to 4-Pin SWC cable for the aermarket radio you are using.

OPTION A is used for ALPINE, CLARION, JVC, and KENWOOD units (Blue/Yellow wire is aached)

OPTION B is used for BLAUPUNKT, BOSS, DUAL, FARENHEIT, JENSEN, POWER ACOUSTIK, PIONEER,

SONY, SOUNDSTREAM and Most O-Brand Radios.

NOTE: Cap or insulate the 3.5mm plug or Blue/Yellow wire if not being used.
