Side 1/4

CHRYSLER DODGE

2011 – 201 3004 – 2011 2014 Charger

– 2011 2015 Journey

Uconnect 8.4” Screen / 2 piece radio with 22 -pin connector

UC-2 Interface Module

CH-22 Harness

CH- 22

Harness

rev.052115

UC-2 Interface

Module

Rear-view camera

Rear of

Headunit

Grey female

22- pin connector

Vehicle harness

White female

22- pin connector

Vehicle harness

+12V Rear- view camera (max. 500mA)

Video in Motion selective (optional)

1

continued

DIP Switch Setting

Vehicle/ navigation

DIP 1

DIP 2

DIP 3

DIP 4

DIP 5

DIP 6

Video in- -motion permanent

ON

ON

OFF

OFF

OFF

OFF

Video in- -motion selective*

OFF

ON

OFF

OFF

OFF

OFF

* With DIP 1 set to OFF, the green wire is used to activate selective - - video in motion function.

DIP -2 switch functions of the UC

DIP – 1 Activate Video in Motion

DIP – 2 Activate Rear- view camera

DIP – 3 no function

DIP – 4 no function

DIP CAN – 5 -bus termination resistor on the vehicle side

DIP CAN – 6 - - bus termination resistor on the head unit side

Pin-assignment (8pin Molex)

Cable colour

Pin- No.

Assignment

● Yellow

Pin 4

CAN HIGH - – connection to the head-unit

● Blue

Pin 3

CAN-LOW – - connection to the head unit

●● Yellow/Black

Pin 8

CAN HIGH - – connection to the vehicle

●● Blue/Black

Pin 7

CAN-LOW – connection to the vehicle

● Red

Pin 1

+12V Constant

● Black

Pin 5

Ground

● Green

Pin 6

Activation of the video- - in motion function

(+12V = Video In Motion, only if DIP1=OFF)

● White

Pin 2

Reverse Trigger output (+12V DC 500mA)

(only if DIP2=ON and reverse gear engaged!)

2 / 4

rev.052115
