Side 1/6

VRFPR-66F

Rear & Front View Integration Interface

for Porsche Vehicles with PCM 3 & 3.1 Navigation Systems

INTERFACING SOLUTIONS

Sightline

Multi View Integration

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

rev.031220

1 of 6

• Rear & Front View Camera Inputs

• Oponal coding of ParkAssist to retrot factory PDC

• Automacally switches screen to Rear-view when Reverse gear is engaged and to Front camera view when gear is

engaged to drive

• Manual acvaon of the front camera using the steering wheel control buon

• Plug & Play Installaon

• Video in Moon funcon

PRODUCT FEATURES:

PARTS INCLUDED:

VRFPR-66F Module VRFPR-66F Harness CUL-16 Rear-View Camera

INSTALLATION DIAGRAM:

Female Quadlock

Vehicle Harness

Rear-View

Camera Input

OEM Rear-View Camera

Front-View

Camera Input

Rear-Vew Camera

(CUL-16 Included)

Front-View Camera

(not Included)

Rear Camera Output 12V (GREEN)

Front Camera Output 12V (WHITE)

Male Quadlock

Connector behind the

headunit

Crux Interfacing Solutions • 21541 Nordhoff St., Unit C, Chatsworth, CA 91311

phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com

rev.031220

2 of 6

INTERFACING SOLUTIONS

Sightline

Multi View Integration

DIP SWITCH SETTINGS:

INSTALLATION INSTRUCTIONS:

CONNECTING THE INTEFACE MODULE

1. Remove the headunit.

2. Connect the female 12-Pin Molex connector of the VRFPR-66F T-harness to the interface module.

3. Unplug the female Quadlock connector from behind the headunit and plug it into the VRFPR-66F T-harness.

4. Plug the male Quadlock of the VRFPR-66F T-harness to the headunit.

CONNECTING THE FACTORY REAR-VIEW CAMERA (Compable with NTSC cameras only)

5. If the OEM rear-view camera will be used, plug in the male RCA labeled “OEM Rear-View Camera” to the female RCA

labeled “Rear-View Camera”.

CONNECTING THE AFTERMARKET CAMERAS (Compable with NTSC cameras only)

6. If using an aermarket rear-view camera, install the aermarket camera behind the vehicle and run the cable towards the

radio. Plug in the male RCA of the aermarket rear-view camer to the female RCA labeled “Rear-View Camera”.

7. Connect the GREEN wire on the T-harness to the 12V power wire of the aermarket camera. The GREEN wire will provide

12 volts power to the camera when the reverse gear is engaged. Power will deacvate automacally when the gear is set

to drive and speed reaches to 12 MPH.

8. If an aermarket front-view camera will be used, install the camera per manufacturer’s installaon instrucons and run

the extension cable towards the radio. Plug in the male RCA of the aermarket rear-view camer to the female RCA labeled

“Front-View Camera”.

9. Connect the WHITE wire on the T-harness to the 12V power wire of the aermarket camera. The WHITE wire will provide

12 volts power to the camera when the gear is set to drive. Power will deacvate automacally when the speed reaches

12 MPH.

Navigaon System DIP 1 DIP2 DIP3 DIP4 DIP5 DIP6

PCM3 with VIM Acvated OFF OFF OFF OFFON ON

PCM3 with VIM Deacvated OFF OFF OFF OFF OFFON

PCM3.1 with VIM Acvated OFF OFF OFFON ON ON

PCM3.1 with VIM Deacvated OFF OFF OFF OFFON ON

DIP SWITCH FUNCTIONS:

DIP 1 = Video in Moon Acvaon

DIP 2 = ON for OEM Rear View Camera / OFF for Aermarket Rear View Camera

DIP 3 = Rear View Camera Coding (see page 3)

DIP 4 = ParkAssist Coding for PCM3.1 systems only (see page 4)

DIP 5 = Camera/ParkAssist Coding (see page 5)

DIP 6 = CAN Bus Terminaon

The interface module is installed behind the headunit.

VRFPR-66F

Rear & Front View Integration Interface

for Porsche Vehicles with PCM 3 & 3.1 Navigation Systems
