Side 1/32
Installation Instructions
Renaissance® Wall Mount Range Hoods
Models RNHP30, RNHP36, and RNHP48
Part No. 109172 Rev. A
APPROVED FOR USE WITH ALL DACOR® RANGES AND COOKTOPS.
TESTED IN ACCORDANCE WITH THE LATEST EDITION OF ANSI/UL 507
STANDARD FOR ELECTRIC FANS AND CAN/CSA-C22.2 NO. 115 STANDARD
FOR FANS AND VENTILATORS.
Planning the Ductwork .....................................................
9
Preparing the Mounting Location ....................................
11
Installation Instructions ..................................................
12
Marking the Centerlines ................................................
12
Installing the Holding Brackets .......................................
13
Rotating the Blower(s) for Rear Exhaust .......................
14
Assembling the Filters ....................................................
18
Using the Dual to Single Transition Kit# AHT10 ............
19
Hanging the Range Hood ..............................................
21
Hardwiring the Hood ......................................................
22
Verifying the Setup .........................................................
24
The Installation Checklist ...............................................
25
Wiring Diagrams ..............................................................
26
Table of Contents
Before You Begin...
Important Safety Instructions ..........................................
1
Important Information About Safety Instructions ..............
1
General Safety Precautions .............................................
2
Product Specifications ....................................................
3
General Specifications .....................................................
3
Weight Specifications .......................................................
3
Dimensions 4
......................................................................
Preparation and Setup ......................................................
6
Parts List ..........................................................................
6
Necessary Tools and Hardware .......................................
6
Meeting Electrical Codes .................................................
7
Installing the Electrical Source .........................................
7
Meeting Installation Requirements ...................................
8
All specifications subject to change without notice. Dacor assumes no liability for changes to specifications.
© 2008 Dacor, all rights reserved.
Important:
• Installer: In the interest of safety and to minimize problems, read these completely and Installation Instructions
carefully before you begin the installation process. Leave these installation instructions with the consumer.
Write the Data Plate Information in the Use and Care Manual before installing the unit.
• Customer: Keep these for future reference and the local electrical inspector’s use.Installation Instructions
If You Need Help...
If you have questions or problems with installation, contact your Dacor dealer or
the Dacor Customer Service Team. For repairs to Dacor appliances under war-
ranty call the Dacor Distinctive Service line. Whenever you call, have the model
and serial number of the appliance ready. The model and serial number are
printed on the appliance data plate.
Dacor Customer Service Team
Phone: (800) 793-0093 ex. 2813 (U.S.A. and Canada)
Monday — Friday 6:00 a m p m. . to 5:00 . . Pacific Time
Web site: www.dacor.com
Dacor Distinctive Service (for repairs under warranty only)
Phone: (800) 793-0093 ex. 2822 (U.S.A. and Canada)
Monday — Friday 6:00 a m p m. . to 5:00 . . Pacific Time
Appliance Data Plate
The appliance data plate is a label that:
• has the model and serial number information and electrical requirements.
• is located inside the hood, above the filters on the back wall of the chassis.
Remove the filters to view it.
