User’s manual

Weather station with wireless outdoor sensor

WS-2200

Overview:

Indoor unit:

1. Display:

Shows time, indoor and outdoor temperature and

weather forecast.

2. SNOOZE / LIGHT button :

Snooze button for the alarm function.

Also turns on the display lighting.

3. ALARM SET button :

For checking and setting the wake-up alarm.

4. CH/+ button:

Selection button when using multiple outdoor units

and the ‘+’ button during setup.

5. MEM/- button:

Memory button when checking min and max val-

ues and the ‘-’ button during setup.

6. DISPLAY SET button:

Function setup button.

7. °C / °F switch:

To switch the temperature display between

degrees Celsius and degrees Fahrenheit.

8. SENSOR button:

To pair the indoor unit with the outdoor unit.

9. RCC button:

To turn the DCF receiver on or off.

10. RESET button:

To restart the indoor unit in case of a (possible)

error.

11. Battery compartment.

Outdoor unit:

1. Monitor-LED:

Illuminates as soon as the outdoor unit is sending

measurement data to the indoor unit.

2. CH 1.2.3 switch:

To set the outdoor unit to a different channel.

3. RESET button:

To restart the outdoor unit in case of a (possible)

error.

4. Suspension eye:

Provision to suspend the outdoor unit from a wall.

5. Battery compartment.

Power supply:

Indoor unit:

Slide down the battery cover at the rear of the unit

and insert 2 AA 1.5V batteries according to the mark-

ings inside the battery compartment. Slide the battery

cover back onto the indoor unit.

The indoor unit will now start a 1 minute scan to

search for the outdoor unit. Therefore, you’ll need to

insert the batteries into the outdoor unit within that

minute.

Outdoor unit:

Slide down the battery cover at the rear of the unit,

slide the CH switch to the position ‘1’ and insert 2 AA

1.5V batteries according to the markings inside the

battery compartment. Slide the battery cover back

onto the outdoor unit.

Weak battery warning:

As soon as the batteries of the outdoor unit become

exhausted, the symbol will illuminate on the

display of the indoor unit.

Now please replace the batteries of the outdoor unit.

The indoor unit does not provide a battery warning.

Replace the batteries of this unit as soon as the

display becomes dim or weak.

Pairing the indoor unit / outdoor unit:

Automatically:

As soon as you insert the batteries into the indoor

unit, the indoor unit will start a 1 minute scan to

search for the signal of the outdoor unit. Therefore,

if you insert the batteries into the outdoor unit within

that minute and the units will ‘nd’ each other, they

will be automatically paired and the display of the

indoor unit will show the temperature transmitted by

the outdoor unit.

Manually:

If the units cannot be paired automatically, or after

replacing the batteries, you can pair the outdoor unit

(again) with the indoor unit as follows:

1. use a sharp object to briey press the RESET

button on the rear of the indoor unit

2. use a sharp object to briey press the RESET

button on the rear of the outdoor unit

3. the units will nd each other (again) after several

seconds and the indoor unit will display the tem-

perature transmitted by the outdoor unit.

Clock:

Introduction

The WS-2200 is provided with a built-in DCF receiver

which receives the DCF time signal from Frankfurt.

This signal ensures that the clock shows the time

very accurately, provided a strong enough signal is

being received.

Automatically:

As soon as you insert the batteries into the indoor unit,

the clock will start searching for the DCF radio signal

for the time while the antenna symbol is ashing.

After several seconds or minutes the WS-2200 will

start showing the correct time. In extreme cases, it can

take over a day before the DCF time is shown.

Manually:

If the clock cannot receive the radio signal or cannot

receive it well enough, you can set the clock manually

as follows:

1. press and hold the DISPLAY SET button for

2 seconds, 12Hr or 24Hr will appear in the display

2. use +/- to set the time format, then briey press

the DISPLAY SET button

3. use +/- to set the hours and then briey press the

DISPLAY SET button

4. use +/- to set the minutes and then briey press

the DISPLAY SET button

5. use +/- to set the seconds to 0 (this allows you to

have the clock run synchronously with your own

clock) and then briey press the DISPLAY SET

button

6. use +/- to set the hour difference compared to the

DCF time. E.g. for use in the Benelux select ‘0’

and then briey press the DISPLAY SET button

The clock is now set manually.

When the DCF receiver is enabled and a strong

signal is being received, the receiver will overwrite

the clock display.

Switching the DCF receiver on/off:

You can turn off the DCF receiver as follows, allowing

you to have only the time and date shown on the

display according to your programming:

• turn off: press and hold the RCC button at the

rear of the indoor unit for 4 seconds until the

antenna symbol disappears.

You can turn the receiver back on as follows:

• turn on: briey press the RCC button at the rear of

the indoor unit until the antenna symbol starts

ashing

‘DST’ in the display.

‘DST’ stands for Daylight Saving Time.

‘DST’ illuminates when the displayed time is the

daylight saving time.

1 2 3 4

433MHz

THERMO SENSOR

RESETCH 1 2 3

Alarm

Setting & turning on the wake-up alarm:

1. press and hold the ALARM SET button for

2 seconds

2. use +/- to set the hours and briey press the

ALARM SET button

3. use +/- to set the minutes and briey press the

ALARM SET button, the alarm time is now saved

(and is also activated immediately)

Switching on/off:

Briey press 2x the ALARM SET button. When

the wake-up alarm is currently enabled, “ ” will be

shown; if “ ” is not illuminated, the alarm is disabled.

Operation:

• As soon as the set time is reached, the alarm will

sound for up to 120 seconds.

• Press the ALARM SET button to stop the alarm

signal earlier or press the SNOOZE/ LIGHT but-

ton to enable the snooze function; the wake-up

alarm will then sound again after 5 minutes.

• The alarm is repeated daily.

Temperature display

Use the °C / °F switch at the rear of the indoor unit

to display the temperature in degrees Celsius or in

degrees Fahrenheit.

The symbol is followed by the indoor temperature.

Behind that the outdoor unit is shown from out-

door unit 1.

Use the CH button at the rear of the indoor unit to

display the temperature from outdoor unit 2 or 3 or

press and hold the CH for 2 seconds to automatically

start scrolling through all channels. Briey press the

CH button to stop this scan.
