Side 1/5
EL 40 GB 09 2023
1
GB
06/2024
Please refer to the numbered drawings which correspond to the paragraph
numbers of the instructions manual.
Contents
Introduction 1
Installation 1
Use, safety 2
Cleaning and hygiene 3
Fault nding 3
Maintenance 4
Conformity with regulations 5
1.1 DESCRIPTION
• This salad dryer is intended for use in kitchens (restaurants,
small caterers) to dry leafy vegetables (lettuce, cress, parsley,
Swiss chard, spinach, cabbage, etc.) and vegetables (radishes,
green beans, diced vegetables, etc.).
A 18/10 stainless steel body
B Drying chamber
C Hinged lid
D Electric controls
E Controls
1.1
2.2
2.1
2.1
It is not designed to dry fabrics or other products.
F Resin basket, 32 litre capacity
G Water outlet
H Motor
I Feet
J Suction cups
Installation
Dimensions of packaging (mm) : 790 x 630 x 1140
Overall dimensions (mm) : 540 x 466 x 800
2.1 DIMENSIONS - WEIGHT
Gross weight packaged : 44.5 kg
Net weight with equipment : 29.5 kg
2.2 LOCATION
• The salad dryer requires :
- An electrical power supply (see § 2.3).
- An outlet to the drain, either direct, by positioning the outlet pipe
above a drain grid, or by connecting it to the drain by means
of a female - female elbow A and a exible plastic pipe B dia.
32 mm.
Note : Leave sucient space above the machine to open the lid 
and remove the basket.
• Unpacking the machine and xing the suction cups:
Remove the box, then unscrew the 3 screws H M8x50 (size 13
spanner) + nuts M8 xing the machine onto the pallet. Retrieve
the bag containing the suction cups from inside the machine (in
the drying basket). Put the suction cups in position on the feet of
the machine, from the bottom, then install the washers and cap
nuts from above, and nish by tightening the assembly.
• The machine may be stood :
- ,On the oor
- On a perfectly stable, horizontal support, non-resonant and
of a maximum height of 450 mm. Leave su󰀩cient space above
the machine to open the lid and remove the basket.
Note :  If  the  machine  is  not  held  solidly  enough,  attach  it  by 
counter-drilling the 3 feet holes. Use the suction cups to dampen 
the attachment (screws and rawl plugs not supplied).
The reference language for these instructions is French.
2.3 ELECTRICAL CONNECTION
ATTENTION!!
Connection to the electrical power supply must be done according to proper professional practice by a qualied and authorised
person (see current standards and legislation in the country of installation).
If an adapter is used on the socket, a check must be made that the electrical characteristics of this adapter are not lower than
those of the machine.
Do not use multiple plugs
The AC power supply to the machine must comply with the following conditions (EN60204-1);
- Maximum voltage variation: ±10%
- Maximum frequency variation: ±1% on a continuous basis, ± 2% over short periods
ATTENTION: the electrical installation must comply (for design, creation and maintenance) with the legal and standard
requirements in the country where used.
- Check that the electric mains voltage, the value shown on the specication plate.
- The machine’s electrical power supply must be protected against voltage surges (short-circuits and excess voltages) using a
circuit breaker compliant with IEC60947-2 properly sized, of the appropriate gauge relative to the place of installation and ma-
chine specications.
ATTENTION: Concerning protection against indirect contact (depending on the type of power supply provided and
connection of the exposed conductive parts to the equipotential protection circuit), refer to point 6.3.3 of EN 60204-1 (IEC
60204-1) with the use of protection devices for automatic shut-o󰀨 of power in the event of an insulation fault with a TN or
TT, system, or for the IT system, with the use of a permanent insulation or di󰀨erentials controller for automatic shut-o󰀨.
The requirements of IEC 60364-4-41, 413.1 must apply for this protection.
For example: in a TN or TT system, a di󰀨erential circuit breaker must be installed upline of the power supply, with a
suitable power cut-o󰀨 (e.g.: 30 mA) on the earthing installation for the place where it is planned to install the machine.
ATTENTION: Failure to comply with these instructions means the customer runs the risk of machine failure and/or acci-
dents due to direct or indirect contacts.
F Nominal current (Amperes)
G Approximate electrical consumption (kWh)
2.3
• A single phase supply via the moulded-on plug must be used
to power the machine.
• Provide an accessible standardized wall outlet with 2 poles
+ ground, rated at 10/16A in accordance with IEC60309, and a
corresponding waterproof plug to be installed on the power cord
and accessible for the operator.
The machine must be earthed with a green / yellow wire.
• The plug must be placed so that the machine may be easily
unplugged after use.
• Electrical characteristics :
A Motor code
B Number of phases (1 single phase)
C Nominal voltage (Volts)
D Motor frequency (Hertz)
E Nominal output (Watts)
To PAT test the Electrolux Range of Food Preparation Equipment,
the PCB board needs to be disconnected before any test is done.
This is due to the fact that the boards are tted with a grounding
diode that can give incorrect result during such a test. Also on a
standard appliance a ash test of 25 amps and up to 3000v is
used but, as you would expect, to use this on equipment, which
has a printed circuit, board would be quite destructive to that
board. We would recommend the use of a PAT tester approved
for computer systems which use a lower rate of amps.
The appliance is perfectly safe and is CE certicated. There are
two ways to get overcome this problem.
· Disconnect the board as instructed and test using test for PC’s,
· Or install the mixer on a fused spur (no plug) as this takes it
away from being a portable appliance and the PAT test is then
not needed.
Use, safety
3.1 OPERATION - SAFETY :
• The safety of the user is guaranteed by :
- the motor stopping when the lid is opened.
- the START button needing to be pressed again after the machine
has been stopped (no-volt release).
- the instructions contained in this leaet being observed for the
cleaning and maintenance of the machine.
a) Starting the machine
- Close the lid.
b) Selecting the drying cycle
- Special fragile products cycle (lettuce, etc.) :
Timed operation
1 – Select time shown at E by pressing keys A and B
2 – Start by pressing key D
3 – Stop once time set has expired, or by pressing key C
N.B.
- To change the time currently running, press key C then change
the setting using keys A and B, and resume cycle by pressing
key D.
- The time selected at the beginning of the cycle is stored in the
memory.
- To cut the current cycle short, press key C twice. -
Normal less-fragile products cycle (curly lettuce, cress, spinach,
leeks, etc.) :
Automatic operation
1 – Start automatic operation by pressing key F
2 –
Stop at the end of the automatic cycle or by pressing key C
N.B. Automatic cycle with 4 stop/start phases
Automatic cycle is 1'20".
c) Stopping the machine
- Automatically at the end of the cycle.
- When the lid is opened in mid-cycle.
Any other use than that described in this manual will
not be considered normal by the manufacturer.
EL 40 GB 06 2024
2
