THANK YOU
• Thank you for purchasing your Dracast PLUS Series LED500. We’re
condent that your Dracast light will provide years of reliable service.
• Please review this instruction booklet before using your Dracast light.
• To ensure proper continued operation, only use the power supply that is
included with your Dracast LED500.
• To protect your eyes, do not look directly into the LED500 while it is
powered on.
• To prevent electric shock, the LED500, power supply, and any batteries
should be kept away from water or excessive moisture. Never submerge
the LED500 or power supply.
• Make sure that the ventilation slots on the back of the LED500 are clear
during operation. Covering these vents will cause the unit to overheat and
possibly malfunction.
• To extend the life of the LED500, turn the unit o when it is not in use.
• Store the LED500 in a clean, dry place with good ventilation. Do not store
the LED500 in direct sunlight for extended periods.
• In case of malfunction, do not open your Dracast LED500 unit. Please
consult your nearest Dracast repair center for assistance. Opening the
Dracast unit will void its one-year warranty.
FEATURES
• Anodized aluminum frame and all-metal chassis
• DIgital LCD display with light output, color temperature, and DMX address
• Local and remote DMX control
• 95 CRI (Color Rendering Index) for ultra-pure light
• High output. Up to 5500 Lux or 511 Footcandles
• V-Mount and Gold Mount battery plates included
• Included mounting yoke for use with 5/8” (baby pin) studs
• Locking yoke knobs
• Optional barn doors, lters, soft boxes, batteries, and more
• x1 Dracast PLUS Series LED500
• x1 12V A/C Power Supply for LED500
• x1 5/8” Mounting Yoke
• x1 Nylon soft carrying case
• x1 Clear plastic LED board protector
• x1 V-Mount battery plate
• x1 Gold-Mount battery plate
INCLUDED IN THE BOX
