CAP300

User Manual

11-2020 / v1.1

CONTENTS

I. Product Information .............................................................................. 1

I-1. Package Contents ............................................................................................................ 1

I-2. System Requirements ...................................................................................................... 1

I-3. Hardware Overview ......................................................................................................... 2

I-4. LED Status ........................................................................................................................ 3

I-5. Reset ................................................................................................................................ 4

I-6. Safety Information ........................................................................................................... 5

II. Quick Setup ........................................................................................... 6

II-1. Initial Setup ...................................................................................................................... 6

II-2. Basic Settings ................................................................................................................... 8

III. Hardware Installation ........................................................................... 12

III-1. Connecting the access point to a router or PoE switch ................................................ 12

III-2. Mounting the access point to a ceiling .......................................................................... 13

III-3. T-Rail Mount .................................................................................................................. 16

IV. Browser Based Configuration Interface ................................................. 18

IV-1. Information .................................................................................................................... 20

IV-1-1. System Information ....................................................................................................... 20

IV-1-2. Wireless Clients ............................................................................................................. 23

IV-1-3. Wireless Monitor ........................................................................................................... 24

IV-1-4. Log .................................................................................................................................. 25

IV-2. Network Settings ........................................................................................................... 27

IV-2-1. LAN-Side IP Address ....................................................................................................... 27

IV-2-2. LAN Port ......................................................................................................................... 29

IV-2-3. VLAN .............................................................................................................................. 30

IV-3. Wireless Settings ........................................................................................................... 31

IV-3-1. 2.4GHz 11bgn................................................................................................................. 31

IV-3-1-1. Basic ............................................................................................................................... 32

IV-3-1-2. Advanced ....................................................................................................................... 35

IV-3-1-3. Security .......................................................................................................................... 37

IV-3-1-3-1. No Authentication ......................................................................................................... 38

IV-3-1-3-2. WEP ................................................................................................................................ 39

IV-3-1-3-3. IEEE802.1x/EAP .............................................................................................................. 39

IV-3-1-3-4. WPA-PSK ........................................................................................................................ 39

IV-3-1-3-5. WPA-EAP ........................................................................................................................ 40

IV-3-1-3-6. Additional Authentication ............................................................................................. 40

IV-3-1-4. WDS ............................................................................................................................... 42

Produkt Specifikationer

Mærke:	Edimax
Kategori:	Adgangspunkt
Model:	CAP300-3SB
Bredde:	- mm
Dybde:	176 mm
Højde:	32 mm
Vægt:	287.3 g
Produktfarve:	Hvid
Opbevaringstemperatur (T-T):	-20 - 60 °C
Relativ luftfugtighed ved drift (H-H):	0 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	0 - 90 %
Ethernet LAN-porte (RJ-45):	1
Strømforbrug (typisk):	6.5 W
Driftstemperatur (T-T):	0 - 50 °C
Ethernet LAN-datahastigheder:	10,100,1000 Mbit/s
Sikkerhedsalgoritmer:	802.1x RADIUS, EAP-PEAP, HTTPS, SSH, SSID, WEP, WPA, WPA2
Certificering:	CE / FCC
Placering:	Loft
Netværksstandarder:	IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az
Modtager, følsomhed:	802.11b\n≤-95dBm@1Mbps\n≤-90dBm@11Mbps\n802.11g\n≤-91dBm@6Mbps\n≤-75dBm@54Mbps\n802.11n\n≤-93dBm@MCS0\n≤-73dBm@MCS7\n≤-90dBm@MCS8\n≤-70dBm@MCS15
Understøttede netværksprotokoller:	IPv6, PPTP, L2TP/IPsec
Antenner, antal:	2
Knap til nulstilling:	Ja
WPS trykknap:	Ja
Servicekvalitet support (QoS):	Ja
LED-indikatorer:	Strøm
Udgangsspænding:	12 V
Udgangsstrøm:	1 A
AC-adapter inkluderet:	Ja
Antal brugere:	50 bruger(e)
Intern:	Ingen
Maksimal dataoverførselshastighed:	300 Mbit/s
Wi-Fi-datahastighed (maks.):	300 Mbit/s
Strøm over Ethernet (PoE):	Ja
Monteringssæt:	Ja
VLAN understøttelse:	Ja
Filtrering af MAC-adresser:	Ja
2.4 GHz:	Ja
5 GHz:	Ingen
Antennefunktioner:	Integreret antenne
Antal SSID understøttet:	16
Niveau for antennestyrke (maks.):	2.82 dBi
Trådløs isolation:	Ja
Wi-Fi-multimedie (WMM)/(WME):	Ja
Automatisk trådløs forsendelsessystem (WDS):	Ja
Strømforsyning:	6 W
