Side 1/6

MADE IN CZECH REPUBLIC

The great advantage is the possibility of changing the reference room by simply relocating the transmitter

part, in which way an optimum temperature comfort can be achieved in the room heated. The coverage

of the set can reach up to 35 m. The receiver is equipped with a code self-learning system and the

E-EPROM memory, which can keep the code saved even at power failure. The possibility of setting up

to 4 time periods and temperatures for every day provides for optimum distribution of electric energy

for all week. An ideally selected program will help you to reduce heating costs by up to 30 %.

• Receiver power supply 230 V/ 50 Hz.

• Receiver with the CODE SELF-LEARNING

system and the E-EPROM memory (saving

the code even at power failure).

• Two-wire connection to the boiler.

• Indication LED for signalization of the

states

- power supply indication

- signal transmission / reception

- failure state

- relay closed.

receiver – wall-mounted

transmitter

• Weekly program

• 4 temperature changes per every day

• Programming by 30 minutes and 0.5 °C

• Programming by day or Mon-Fri, Sat-Sun

or Mon-Sun

• Hysteresis 0.5 °C

• Possibility of short-term temperature

change

• Key lock

• Sum of boiler operating hours

• Manual mode (MANU)

• Permanent switch-off (OFF)

• Anti-freeze mode (3 °C)

• TEST function

• Supplied by alkaline batteries

2 × 1.5 V/AA

- freely portable

- small dimensions

- simple operation

- possibility of using

the stand (included

in the delivery)

TWO-WAY COMMUNICATION

- providing for reliable signal transmission and

enabling return information acquisition.

RECEIVER CONTROL ELEMENTS

CODE LEARNING

230 V/50Hz

To be used if the receiver memory has been erased – the red diode is ﬂ ashing!

1) Push the receiver’s “FUNCTION BUTTON” for about 1.5 sec; the blue and red LEDs start

ﬂ ashing alternately; and the receiver is awaiting the code (“learning mode”).

2) After insetting batteries into the transmitter (see page 3), push the Fce , button; select the tE:St

function with the / button and conﬁ rm it with the i button (the message appears on the Ad:r

display); conﬁ rm with the i button (the code will be sent to the receiver).

3) The code receipt in the receiver is indicated by simultaneous ﬂ ashing of the blue and red LED; thus the

code has been learnt. After the code receipt, the output relay is switched several times to verify correct

function of BPT 102 (On/OFF is displayed on the transmitter).

Lifting off the front cover:

Fig.1 Fig.2

Indication LEDs:

GREEN LIT - correct connection to the mains

BLUE FLASHES shortly - during communication with the transmitter

RED FLASHING - empty E-EPROM memory

RED LIT - FAILURE (if no signal from the transmitter is received within approx. 6

hours, it switches to the “2-min-ON / 8-min-OFF” mode)

BLUE+ FLASHING ALTERNATELY - code learning modeRED

BLUE+ FLASHING SIMULTANEOUSLY - code has been learnedRED

BLUE+ LIT SIMULTANEOUSLY - memory erasure modeRED

ORANGE LIT - relay 1 switched

holes for mounting on KU/KP68

FUNCTION BUTTON

- short push (approx. 1 s) =

CODE-LEARNING mode

- long push (approx. 5 s) =

RESET (memory erasure)

output terminals for

the boiler

(potential-free

switching contact)

power supply

terminals

RECEIVER INSTALLATION

- Lift off the front cover of the receiver acc. to Fig. 1, 2.

- Fix the receiver to the wall (or directly to the wiring box).

- Switch off the main circuit breaker.

- Connect the receiver to the boiler according to the diagram (on the boiler, use the terminals for wires of

the room thermostat 2).

- Connect the receiver to the mains 230 V / 50 Hz.

- Switch on the main circuit breaker; the green LED lights up on the receiver; thus the receiver is ready

for further setting

Owing to disturbance of the signal reception, install the receiver (in the interior) as far as possible (no

less than 0.5 m) from big metal objects and outside high-current power lines! We recommend that the

installation be done by a person properly qualiﬁ ed in electrical engineering!

Wiring diagram: BOILER
