Electro 56 LED

SPECIFICATIONS:

Model: Electro 56 LED

LED’s: 108 (36 Red, 36 Green,

and 36 Blue)

Weight: 3.85lbs./ 1.75kgs.

Size: 6.88” (H) x 8.26” (W) x

8.6” (D)

Fuse: 1 Amp

Supply Voltage: 90v/240v ~ 60Hz/50Hz

Working Position: Any Safe position

Duty Cycle: None

DMX Channels: 4

Colors: Multiple Colors

Warranty: 1 Year

CAUTION! Please read and

understand these instructions

before installing or operating

this unit.

Operating Instructions:

The Electro 56 LED has been tested at the factory, there is no assembly required. The unit is ready

to be plugged into a power outlet. This unit is a 4 channel DMX intelligent LED par can. It can be run

as a stand-alone unit, DMX controlled unit, or in a Master/Slave configuration. While in Stand Alone

or a Master/Slave configuration, you can run the auto mode, sound active mode, or control the col-

ors manually. For stand-alone mode, Master/Slave configuration, and DMX Control see other side.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Caution! Never open unit when in use.

Always disconnect main power before

replacing fuse. Remember to always

replace with the exact same type fuse.

1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our

1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with

dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover

items or parts prone to wear and tear: lamps, leds, fuses, brushes and belts. Eliminator Lighting war-

ranty is only valid with-in the United States.

©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com

Universal DMX Control: This unit allows you to use any universal DMX-512 controller to control the

different DMX traits. A DMX controller allows you to create unique programs tailored to your individu-

al needs.

1. The Electro 56 LED uses four DMX channels.

2. To control your fixture in DMX mode, follow the set-up specifications that are included with your

DMX controller.

3. Set dipswitch 10 to the “On” position.

4. Use the controller’s faders to control the various DMX fixture traits.

5. For longer cable runs (more than a 100 feet) use a terminator on the last fixture.

6. For help operating in DMX mode consult the manual included with your DMX controller.

Master-Slave Operation: This function will allow you to link up to 16 units together and operate with-

out a controller. In Master-Slave operation one unit will act as the controlling unit and the others will

react to the controlling units operation. Any unit can act as a Master or as a Slave.

1. Using standard XLR microphone cables, daisy chain your units together via the XLR connector on

the rear of the units. Remember the Male XLR connector is the input and the Female XLR con-

nector is the output. For longer cable runs we suggest a terminator at the last fixture.

2. The dipswitch settings for Master/Slave mode is as follows: Master unit set your desired running

mode, then connect the slave units and set dipswitches 1 & 10 to the “On” position.

Stand Alone (Manual Mode with Strobe):

1. Plug the fixture in, dipswitch controls are as follows: dipswitch 1 is Red, dipswitch 2 is Green,

and dipswitch 3 is Blue.

2. Use dipswitches 4-6 to control the speed of the strobe.

Stand Alone (Auto Mode):

1. Plug the fixture in, and put all dipswitches in the “Off” position. Use dipswitches 7 & 8 to control

the color fade speed.

Stand Alone (Sound Active Mode):

1. Put dipswitch 9 in the “On” postion.

DMX TRAITS:

CHANNEL 1: RED

0 - 255 = 0% - 100%

CHANNEL 2: GREEN

0 - 255 = 0% - 100%

CHANNEL 3: BLUE

0 - 255 = 0% - 100%

CHANNEL 4: DIMMER/STROBE

0 - 189 = DIMMER 0% - 100%

190 - 250 = STROBE SLOW - FAST

251 - 255 = NO FUNCTION
