ESM-XX30 Process Control Units

ENGLISH

ESM-4430, ESM-7730, ESM-9930, ESM-4930, ESM-9430

Universal Input PID Process Controllers

- 4 digit process (PV) and 4 digit set (SV) display

- Programmable ON/OFF, P, PI, PD and PID control forms

Universal process input (TC, RTD, mV Z, V Z, mA Z)

- Dual or multi point calibration for ZVoltage & Zcurrent inputs

- Auto-tune and Self-tune PID

- Manual/Automatic mode selection for control outputs

- Bumpless transfer

- Programmable heating, cooling and alarm

functions for control outputs

SPECIFICATIONS

PROCESS INPUT

Universal Input: TC, RTD, Z Voltage/Current

Thermocouple (TC): L(DIN 43710) ,J , K , R , S , T , B , E and N

(IEC584.1)(ITS90) ,C (ITS90)

Thermoresistance (RTD): PT-100 (IEC751)(ITS90)Z

Input: mV, V, mA

Measurement Range : Please refer to Table-1 for selection of input

type and scale

Accuracy:± 0.25% of full scale for thermocouple, thermoresistance,

mV, V and mA input.

Cold Junction Compensation:Automatically ±0.1°C/1°C

Line Compensation: Maximum 10 Ohm

Sensor break protection:Upscale

Sampling Cycle:3 samples per second

Input Filter: 0.0 to 900.0 seconds

CONTROL

Control Form: ON/OFF, P, PI, PD or PID (Control form can be

programmed by the user)

Introduction Brochure. ENG ESM-XX30 01 V13 01/23

DISPLAY

Process Display :

ESM-4430 : 10.1 mm Red 4 Digits LED Display

ESM-4930 : 13.2 mm Red 4 Digits LED Display

ESM-7730 : 13.2 mm Red 4 Digits LED Display

ESM-9930 : 19 mm Red 4 Digits LED Display

ESM-9430 : 10.1 mm Red 4 Digits LED Display

Set Value Display :

ESM-4430 : 8 mm Green 4 Digits LED Display

ESM-4930 : 8 mm Green 4 Digits LED Display

ESM-7730 : 9.1 mm Green 4 Digits LED Display

ESM-9930 :10.8 mm Green 4 Digits LED Display

ESM-9430 : 8 mm Green 4 Digits LED Display

LEDS : AT(Auto Tune), M (Manual Mode), A (Automatic Mode),

PSET / ASET1 / ASET2 (Control or Alarm Set) Leds, PO, AO1, AO2

(Control or Alarm Status) °C / °F / V Leds

OUTPUT

Standard Relay Outputs : Two relays. 5A@250VV(at resistive load)

(They can be programmed as Control or Alarm output)

SSR Driver Output : Maximum 17mA , Max. 25V Z

SUPPLY VOLTAGE

100-240 V V 50/60 Hz (-15%;+10%), - 6VA

24V V 50/60 Hz (-15% ; +10%), - 6VA

24V Z (-15% ; +10%), - 6W

(Must be determined in order)

ENVIRONMENTAL RATINGS and PHYSICAL SPECIFICATIONS

Operating Temperature: 0...50°C

Humidity : 0-90%RH (none condensing)

Protection Class : IP65 at front, IP20 at rear

Mounting: Type-1 Enclosure Mounting

Weight:

ESM-4430 : 170 gr.

ESM-4930 : 230 gr.

ESM-7730 : 230 gr.

ESM-9930 : 320 gr.

ESM-9430 : 230 gr.

Dimensions / Panel Cut-Out:

ESM-4430 : (48 x 48mm, Depth:87.5 mm) / (46 x 46mm)

ESM-4930 : (96 x 48mm, Depth:86.5 mm) / (92 x 46mm)

ESM-7730 : (72 x 72mm, Depth:87.5 mm) / (69 x 69mm)

ESM-9930 : (96 x 96mm, Depth:87.5 mm) / (92 x 92mm)

ESM-9430 : (48 x 96mm, Depth:86.5 mm) / (46 x 92mm)

Minimum Distance Between Panel Cut-Out Centers:

ESM-4430 : X=65mm, Y=65mm

ESM-4930 : X=129mm, Y=65mm

ESM-7730 : X=97mm, Y=97mm

ESM-9930 : X=129mm, Y=129mm

ESM-9430 : X=65mm, Y=129mm

Installation: Fixed installation Category II

Over Voltage Category: II

Pollution Degree: II, office or workplace, none conductive pollution
