Side 1/3
FEATURESTECHNICAL SPECS
Thank you for purchasing Erica Synths Pico Series module!
With Pico Series we challenged ourselves can we make ANY
superior functionality synth module 3HP wide and affordable?
Erica Pico INPUT module is just, what you need to interface your
modular system with external synths or even your mp3 player
or mobile phone. It boosts external signal to modular synth
signal level.
Independent L and R inputs
3,5mm stereo input
Independent gain adjustment for L and R channels
Signal level indicator LEDs
Configurable signal boosting (+20dB/+40dB)
Input signal boosting 0 - +20/+40dB (configurable)
Power consumption +18mA, -8mA
Module width 3HP
Module depth 35mm
PICO
INPUT
Connect audio signals from an
external source here! The Left
channel is stereo 3,5mm jack, so you
have an advantage of connecting both
stereo signals or two independent
mono signals.
Adjust Left channel gain with this
potentiometer. The gain of the each
channel is configurable by replacing
jumpers on the main PCB of the module.
Factory setting with a jumper
inserted is +40dB. For +20dB gain
remove a jumper.
Adjust Right channel gain with this
potentiometer
This is Left output
This is Right output
LEDs give visual feedback on the
signal level. The green LED means 0dB,
red - +40dB boosting
PICO
INPUT
PICO
INPUT
IN L/
STEREO
IN R
GAIN L
GAIN R
OUT
