Side 1/4

FEATURESTECHNICAL SPECS

Thank you for purchasing Erica Synths Pico Series module!

With Pico Series we challenged ourselves – can we make ANY

superior functionality synth module 3HP wide and affordable?

Erica Pico Trigger module provides master clock for the Pico

System, as well as it generates up to 16 step patterns of 4

triggers – simple clock divider patterns, and more advanced

polyrhythmic patterns of different step length for triggering

drums. Patterns are user designed in custom web interface, and

can be uploaded to the module via CLK in 3,5mm jack.

Selectable internal clock or external clock

Clock output

Polyrhytmic patterns

Adjustable shuffle

4 trigger outputs

8 pattern memory

Web-based pattern design interface

Pattern upload via CLK input

Clock rate 20BPM – 420BPM

Trigger amplitude 5V

Trigger duration 10ms

Power consumption +20mA, -5mA

Module width 3HP

Module depth 35mm

PICO

TRIGGER

TRIGG

PICO

LOAD

OUT

CLK

IN/OUT SWITCH selects Clock

source. out setting means the

module generates internal clock

and outputs it on CLK jack. in

setting means you can patch the

external clock signal in CLK jack.

The module will start to play

sequence as soon the first clock

signal appears.

The encoder allows you to

access main features of the

module. Push the encoder to move

through different modes.

1) If the encoder is blinking GREEN,

it indicates PATTERN PLAY mode

and stets clock rate.

2) If the encoder is light YELLOW,

it sets shuffle amount. Rotate

the encoder to alter shuffle

amount. The brighter is the

encoder, the more shuffle is

applied.

3) To upload patterns from the

web interface, set the IN/OUT

switch to IN setting and then

push and hold the encoder for

2’’. The encoder will blink RED.

Now you can connect a

laptop/tablet/mobile phone

with pattern designer

interface open to CLK jack and

upload pattern to the selected

memory slot. It will take about

second for upload to complete,

and the encoder will blink

green once. Now you can upload

next pattern, etc. Once you

have uploaded all patterns,

push the encoder promptly,

and it will advance to PATTERN

PLAY mode.

NB! DO NOT CONNECT ANY DEVICE

RUNNING “PATTERN DESIGNER”

TO THE “CLK” PORT WHEN THE “CLK”

IS SET TO “OUT”. BY DOING SO YOU

MIGHT DAMAGE YOUR DEVICES AUDIO

OUT PORT.

Patch external clock TO CLK JACK

or send the internal clock to

other modules. Also use this jack

to upload patterns from

web-based pattern

designer interface.

LOAD button allows you to load

trigger patterns from internal

memory on the fly, even during

performance. Once button is

pressed, Trigger Out LEDs will stop

blinking (but module continues to

send trigger signals)AND WILL

INDICATE PATTERN SELECTION. T1-T4

MEANS PATTERNS 0-3 AND BLINKING

T1-T4 SHOWS PATTERNS 4-7.. Rotate

the encoder to select a pattern

and push the encoder to confirm.

Four LEDs indicate the active

Triggers and selected patterns.

T1, T2, T3 T4AND are

Trigger outputs

PICO

TRIGGER
