car crashes than by any other type of injury.
To reduce the risk of SERIOUS INJURY DEATH or , read
this owner’s manual and your vehicle owner’s manual
before installing and using this child restraint. Using a
child restraint makes a big difference. By properly using
this child restraint and following these instructions (and
the instructions that accompany your vehicle), you will
greatly reduce the risk of serious injury or death to your
child from a crash. Do not be misled by the commonly
used term “safety seat”; no restraint system can prevent
all injuries in all crashes. Many properly restrained
adults and children are injured in motor vehicle crashes,
including relatively minor crashes. A properly used child
restraint is the best way to minimize injuries to your
child and to increase the chances for your child’s survival
in most crashes.
Child Requirements
• No restraint can guarantee absolute protection from
injury in every crash.
• This child restraint is designed for use by children in rear-
facing forward-facing booster modes. , , and
• To use this child restraint properly, children meet
MUST
weight/size specifications as follows:
For Rear-facing Use
• The child weighs 2.3 to 18 kg (5 to 40 lbs).
• The child is 48 to 102 cm (19 to 40 inches) the top of AND
child’s head is at least 25 mm (1 inch) below the top of the
child restraint headrest in either of its two lowest positions.
For Forward-facing Use
• The child weighs 10 to 29.4 kg (22 to 65 lbs).
• The child is 71 to 127 cm (28 to 50 inches) the tops of AND
their ears are below the top of the child restraint headrest.
• Child is one year old or older.
For Booster Use
• The child weighs 18 to 54.4 kg (40 to 120 lbs).
• The child is 112 to 145 cm (44 to 57 inches) the AND
tops of their ears are below the top of the child restraint
headrest.
• Child is four years old or older.
U.S. REGULATORY NOTICE
This child restraint meets all applicable requirements of
Federal Motor Vehicle Safety Standard 213.
CANADIAN REGULATORY NOTICE
(Model numbers ending in “C.”)
This child restraint meets all applicable requirements of
Canadian Motor Vehicle Safety Standards CMVSS 213,
213.1, and 213.2.
