Setup Guide — P/2 DA4xi and P/2 DA6xi

Installation

The Extron P/2 DA4xi and P/2 DA6xi are

distribution ampliﬁers taking one video input

(VGA to QXGA) and distributing it to one

buffered loop-through and three (P/2 DA4xi) or

ﬁve (P/2 DA6xi) individually buffered outputs.

To install and operate either unit, follow the steps

below.

Step 1

Ensure all devices are powered off or electrical cables are disconnected.

Step 2

Choose a suitable location and mount the distribution ampliﬁer on a table, in a

rack, or under a desk.

Step 3

Connect a computer source to the 15-pin HD female input connector of the

distribution ampliﬁer.

Step 4

Connect four (P/2 DA4xi) or six (P/2 DA6xi) high-resolution display devices to

the 15-pin HD output connectors of the distribution ampliﬁer.

Output 1, which is labeled “Local Monitor” is used for DDC reference.

Step 5

Power on the distribution ampliﬁer.

Step 6

Power on the displays.

Step 7

Power on the source.

Troubleshooting

If the video output is “soft” on any display, move the video gain switch on the

rear panel to the up (1V) position.

If no image appears:

Check all the input and output video cables are connected and secure.•

Check all devices are receiving power.•

If the issue still persists, call the Extron support hotline.•

Extron USA - West

Headquarters

+ 6800.633.987

I nside USA / Canada Only

+1.71 04.491.150

+1.71 74.491.151 FAX

Extron USA - East

+ 6800.633.987

I nside USA / Canada Only

+1.919.863.1794

+1.919.863.1797 FAX

Extron Europe

+800.3987.6673

I nside Europe Only

+31.3 5 03.4 3.404

+31.3 5 3.4 3.4050 FAX

Extron Asia

+800.7339.8766

I nside Asia Only

+65.6383.4400

+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+400 83.8 .1568

Inside China Only

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.2991800

+971.4.2991880 FAX

68-991-50 A

02 09

Produkt Specifikationer

Mærke:	Extron
Kategori:	Modtager
Model:	P/2 DA6xi
Vekselstrømsindgangsfrekvens:	50 - 60 Hz
Bredde:	221 mm
Dybde:	152 mm
Højde:	41 mm
Vægt:	900 g
Produktfarve:	Black, White
Pakkevægt:	2000 g
Pakkedybde:	279 mm
Pakkebredde:	279 mm
Pakkehøjde:	1060 mm
Opbevaringstemperatur (T-T):	-40 - 70 °C
Relativ luftfugtighed ved drift (H-H):	10 - 90 %
Relativ luftfugtighed ved opbevaring (H-H):	10 - 90 %
Strømforbrug (typisk):	12 W
Driftstemperatur (T-T):	0 - 50 °C
Certificering:	CE, C-tick, FCC Class A, ICES, KCC, VCCI
Indgangsspænding:	100-240 V
Stativ-montering:	Ja
Sikkerhed:	CE, c-UL, UL
Båndbredde:	350 MHz
VGA (D-Sub) udgangsporte:	6
