Flush-mounting electronic room thermostat suitable to regulate the temperature in heating installations.

C37-38

Flush-mounting room thermostats, 1 temperature

FEATURES

Power supply for 230V 50Hz C37-C37B;

Power supply with 2 AAA alkaline long life batteries for C38-C38B (batteries operation life over 1 year);

Voltage-free switching contact;

Software A class;

Micro disconnection (1B);

 double isolation;

LED to indicate relay (C37-C37B);

LED to check the batteries charge (C38-C38B);

Adjustment knob of big diameter and large-scale;

The batteries are replaced through thermostat’s front (C38-C38B);

Unit weight 0,20 Kg.

C37 - C38 ANTHRACITE

C37B - C38B WHITE

Temperature

regulation

range

Differential*

Body

admissible

temperature

Power supply Contacts

rating

Protection

degree

C37 5 ÷ 30 °C 0,5 - 10 ÷ 50 °C 230V - 50Hz 5(3)A 250Vca IP20

C38 5 ÷ 30 °C 0,5 - 10 ÷ 50 °C 2 batteries AAA 1,5 V 5(3)A 250Vca IP20

* Differential values are referred to a thermal gradient of 4K/h.

Dimensions (mm)

INSTALLATION

Flush-mounting in 3-module 503 embedded boxes by means of 2 screws (supplied);

Two-wire connection with the user;

Install the thermostat at 1,5 meters above the floor, away from kitchens, heat sources, windows and doors.

HOMOLOGATION AND STANDARDS

Complies with EN 60730-1 standards;

ErP Class I; 1% (Reg. EU 811/2013 - 813/2013);

4 FRAMES to provide compatibility with the most common plates

INCLUDED IN THE PACKAGE C37 - C38

INCLUDED IN THE PACKAGE C37B - C38B

1 COVER “A”

ANTHRACITE

1 COVER “A”

WHITE

1 COVER “B”

ANTHRACITE

1 COVER “B”

WHITE

1 PAIR OF ADAPTERS

ANTHRACITE

1 PAIR OF ADAPTERS

WHITE

1 PAIR OF ADAPTERS for Bticino Matix plate

WHITE

1 2 3 4

A B
