ENGLISH
2
BASSBREAKER 007
TM
The Bassbreaker 007 is a versatile 7-watt amp that delivers big,
thick and crunching tone with terrific features and the sound of
pure tube greatness. Bassbreaker guitar amplifiers continue the
acclaimed lineage established by the great Fender Bassman® amp of
the late 1950s, taking classic Bassman design and “breaking” it with
features including unusual-for-Fender circuitry and components,
dark gray tweed covering, refined pointer knobs, and the early
Fender block-letter logo.
With its secret-agent name and distinctive style, the Bassbreaker
007 comes in head and combo models and features a single EL34
output tube for true class “A” operation, a 10” Celestion® Ten Thirty
speaker for tighter rock distortion (combo version), a treble-boost
switch for extra gain and harmonics, and a line output for easy com-
patibility with external recording and sound reinforcement equip-
ment. The Bassbreaker 007 head pairs neatly with the Bassbreaker
BB-112 speaker enclosure.
Register your Bassbreaker 007 online at www.fender.com/product-registration.
Control Panel
A. INPUT: Plug instrument in here.
B. TREBLE BOOST: Pushbutton boost circuit provides extra gain,
harmonics and high-frequency response.
Optional single-button FOOTSWITCH (L) also activates
TREBLE BOOST.
C. GAIN: Adjusts preamp gain and signal overdrive.
D. BASS, MIDDLE, TREBLE: Tone controls.
E. MASTER: Master volume control; use with GAIN (C) to set
overall volume.
F. POWER INDICATOR: Illuminates when Bassbreaker is on.
G. POWER: Turns Bassbreaker on (up) and off (down).
0 10
0 10 0 10 0 10 0 10
INPUT GAIN BASS MIDDLE TREBLE MASTER POWER
TREBLE
BOOST
FENDER MUSICAL INSTRUMENTS BASSBREAKER 007
TM
INPUT POWER
55W
120V 60Hz
F2A L
250V
FUSE
SPEAKER
OUTPUT
7 WATTS
8Ω MIN
LINE
OUTPUT
COMBO ONLY:
MUTES
INTERNAL SPEAKER
SWITCH
FOOT
CAUTION:
TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE BACK COVER.
NO USER SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
CAUTION:
TO REDUCE THE RISK OF FIRE,
REPLACE FUSE WITH SAME TYPE AND RATING
TYPE: PR 3032
SERIAL NUMBER
WARNING:
MAINTAIN 6" CLEARANCE
FOR VENTILATION.
WARNING:
FENDER AMPLIFIER SYSTEMS ARE
CAPABLE OF PRODUCING VERY
HIGH
SOUND PRESSURE LEVELS WHICH MAY
CAUSE TEMPORARY OR PERMANENT HEARING
DAMAGE. USE CARE WHEN
SETTING AND ADJUSTING VOLUME LEVELS DURING USE.
A PRODUCT OF:
FENDER MUSICAL INSTRUMENTS CORP.,
CORONA, CA U.S.A.
MADE IN MEXICO
BASSBREAKER 007
TM
フェンダー·
ミュージック(株)
CAUTION: CHASSIS SURFACE HOT
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS EQUIPMENT TO RAIN OR MOISTURE
AVERTISSEMENT: RISQUE DE CHOC ELECTRIQUE ! NE PAS OUVRIR !
AT TENTION: SUPERFICIE DE CHASSIS CHAUDE
