SIGNAL PAD

Passive Attenuator

Congratulations on your purchase of the Signal Pad. The Signal Pad is a

passive attenuator that allows you to reduce the signal level of your

instrument at the touch of a button. The signal path through the Signal Pad

is completely passive; the effect does not require power to work. The Signal

Pad’s power connection is only for lighting the LED.

- SIGNAL PAD APPLICAITONS -

The Signal Pad is simplicity itself. It’s like having the volume control of your

guitar in a pedal. If you have a classic single channel amp, you basically

have only one gain available to you. The Signal pad allows you to set up an

alternate volume for controlling your amplifier. As an example, if your

amplifier is set for a high gain distortion, you can run through the Signal Pad,

to lower your signal level. As you step on the footswitch, your amplifier will

back down and give you a cleaner tone with the same clarity and

characteristics. You’ve just turned your vintage single channel amp into a

dual channel, foot switchable amp.

You can also use the Signal Pad to set up alternate volumes to drive other

pedals and pedal boards. For example, in front of an envelope follower

pedal, such as the Q-Tron, the Signal Pad will allow you to change the Q-

Tron’s sensitivity. You will be able to switch between two different filter

sounds without the need to bend over and turn the knobs on the Q-Tron.

- CONTROLS -

Volume Knob – Controls the output volume of the Signal Pad.

Status LED - When the LED is lit, the signal pad is active. When the LED is

off, the Signal Pad is in True Bypass mode. Power is required for the LED to

light.

INPUT Jack – This ¼” jack is the audio input to the Signal Pad. The input

impedance presented at this jack is 1M.

OUTPUT Jack – This ¼” jack is the audio output from the Signal Pad.

When the Signal Pad is in Bypass mode, the OUTPUT jack is connected

directly to the INPUT jack.

9V Power Jack – In order to light up the Signal Pad’s LED, a battery must

be installed into the Signal Pad or an external AC Adapter power supply must

be plugged into the Power jack at the top of the Signal Pad. The polarity of

the Power jack is center negative. It requires 9VDC at 25 mA. We

recommend the Electro-Harmonix US96DC-200BI power supply.

- WARRANTY INFORMATION -

Please register online at http://www.ehx.com/product-registration or

complete and return the enclosed warranty card within 10 days of purchase.

Electro-Harmonix will repair or replace, at its discretion, a product that fails

to operate due to defects in materials or workmanship for a period of one

year from date of purchase. This applies only to original purchasers who

have bought their product from an authorized Electro-Harmonix retailer.

Repaired or replaced units will then be warranted for the unexpired portion

of the original warranty term.

If you should need to return your unit for service within the warranty period,

please contact the appropriate office listed below. Customers outside the

regions listed below, please contact EHX Customer Service for information on

warranty repairs at info@ehx.com or +1-718-937-8300. USA and Canadian

customers: please obtain a Return Authorization Number (RA#) from

EHX Customer Service before returning your product. Include with your

returned unit: a written description of the problem as well as your name,

address, telephone number, e-mail address, and RA#; and a copy of your

receipt clearly showing the purchase date.

United States & Canada

EHX CUSTOMER SERVICE

ELECTRO-HARMONIX

c/o NEW SENSOR CORP.

47-50 33RD STREET

LONG ISLAND CITY, NY 11101

Tel: 718-937-8300

Email: info@ehx.com

Europe

JOHN WILLIAMS

ELECTRO-HARMONIX UK

13 CWMDONKIN TERRACE

SWANSEA SA2 0RQ

UNITED KINGDOM

Tel: +44 179 247 3258

Email: electroharmonixuk@virginmedia.com

This warranty gives a purchaser specific legal rights. A purchaser may have

even greater rights depending upon the laws of the jurisdiction within which

the product was purchased.

To hear demos on all EHX pedals visit us on the web at www.ehx.com

Email us at info@ehx.com
