LADYBUG
®
5
USB 3.1
30 MP, 360° SPHERICAL CAMERA IMAGING SYSTEM
The Ladybug5 spherical imaging system boasts an impressive 30 MP resolution covering 90%
of a full sphere; a 5 Gbit/s USB 3.0 interface; and a ground-breaking post-processing workow that
provides high dynamic range, superb image quality and maximum user exibility. It is an excellent
choice for applications in geographic information systems (GIS); vehicle-based photogrammetry;
situational awareness; and entertainment solutions for lighting models, full dome projection content,
and other immersive experiences.
POST PROCESSING WORKFLOW
FOR DYNAMIC RANGE
The workow starts with Ladybug5 capturing, compressing,
and transmitting full bit depth 12-bit RAW images. Users then
use LadybugCapPro’s post processing toolbar to apply white
balance, gamma, smear correction, and other image processing
functions for maximum dynamic range.
USER FLEXIBILITY
The capture and post workow model allows users to maintain
exibility by being able to return to the original content and re-
apply post processing steps as desired.
HIGH BANDWIDTH INTERFACE
Leverages USB 3.0 interface that makes 12-bit RAW imaging
possible.
Hardware Development Kit
KEY FEATURES
www.flir.com/iis
MODEL VERSION MP IMAGING SENSOR
LD5-U3-51S5C-44R
LD5-U3-51S5C-44B
Red
Black
30 MP (5 MP x
6 sensors)
Sony ICX655 CCD x 6, 2/3", 3.45 µm
Global shuer
2048 x 2448 at
10 FPS JPEG Compressed
5 FPS Uncompressed
A/D Converter 12-bit
Image Data Output 8-, 12-, or 16-bit, Raw or JPEG compressed
Image Data Formats Raw8, Raw12, Raw16 in uncompressed and JPEG
Paral Image Modes Pixel binning and region of interest (ROI) modes
Image Processing Shuer, gain, white balance, gamma and JPEG compression, are programmable via soware
Shuer
Global shuer; Automac/manual/one-push/extended shuer modes
0.02 ms to 2 seconds (extended shuer)
Gain
Automac/manual/one-push modes for 8-bit formats; manual mode for 12-bit formats
0 - 18 dB
Gamma 0.50 to 4.00
White Balance Manual
High Dynamic Range Cycle 4 gain and exposure presets
Digital Interface USB 3.0 with locking screws for secure connecon
Transfer Rates 5 Gbit/s
GPIO 12-pin GPIO connector for external trigger input, strobe output, and camera power
External Trigger Modes Standard, bulb, skip frames, overlapped, and mul shot trigger modes
Memory Channels 2 memory channels for custom camera sengs
Case Machined aluminum housing, anodized red or black; single unit, IP65 cerfied
Dimensions 197 mm diameter, 160 mm height (with lens hoods)
Mass 3.0 kg
Power Consumpon 12-24 V, 13 W via GPIO
Machine Vision Standard IIDC v1.32
Camera Control via Ladybug SDK, CSRs, or third party soware
Camera Updates In-field firmware updates
Opcs 6 high quality 4.4 mm focal length lenses
Field of View 90% of full sphere
Spherical Distance Calibrated from 2 m to infinity
Focus Distance ~200 cm. Objects have an acceptable sharpness from ~60 cm to infinity
Environmental Sensors Temperature, Barometer, Humidity, Accelerometer, Compass
Temperature Operang: 0° to 45°C; Storage: -30° to 60°C
Humidity Operang: 20 to 80% (no condensaon) ; Storage: 20 to 95% (no condensaon)
Compliance
Environmental Protecon
CE, FCC, RoHS
IP65
Operang System Windows 7 or Windows 8, 64-bit with 8 GB RAM
Warranty 2 Years
Specifications
