© 2015 Flyzone, a Hobbico company. FLZA3024 Mnl
SPECIFICATIONS
Wingspan: 41.5 in
[1055 mm]
Wing
Area:
297 in2
[19.2 dm2]
Weight: 28 – 31 oz
[795 – 880 g]
Wing
Loading:
13.6 – 15 oz/ft2
[42 – 46 g/dm2]
Length: 34.5 in
[875 mm]
Radio: 4 – 5-channel
(required)
READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION. IT CONTAINS IMPORTANT
INSTRUCTIONS AND WARNINGS CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.
WARRANTY
Hobbico guarantees this kit to be free from defects in both
material and workmanship at the date of purchase. This
warranty does not cover any component parts damaged by use
or modication. In no case shall Hobbico’s liability exceed the
original cost of the purchased kit. Further, Hobbico reserves
the right to change or modify this warranty without notice.
In that Hobbico has no control over the nal assembly or
material used for nal assembly, no liability shall be assumed nor
accepted for any damage resulting from the use by the user of
the nal user-assembled product. By the act of using the
user-assembled product, the user accepts all resulting liability.
If the buyer is not prepared to accept the liability associated
with the use of this product, the buyer is advised to return
this kit immediately in new and unused condition to the
place of purchase.
To make a warranty claim send the defective part or item to
Hobby Services at the address below:
Hobby Services
3002 N. Apollo Dr. Suite 1
Champaign IL 61822 USA
Include a letter stating your name, return shipping address, as
much contact information as possible (daytime telephone
number, fax number, e-mail address), a detailed description of
the problem and a photocopy of the purchase receipt. Upon
receipt of the package the problem will be evaluated as quickly
as possible.
INSTRUCTION MANUAL
®
™
2
INTRODUCTION
Thank you for purchasing the Flyzone Extra 300SX. The
Extra was originally intended as a 3D-capable platform,
but because of its power-to-weight ratio and well-
mannered ight characteristics, the Extra is also a great
sport yer for average pilots when the control throws are
set to low or high rates.
For the latest technical updates or manual
corrections scan the QR code, or visit the
Flyzone web site at www. yzoneplanes.
com. Click the icon at the top airplane
of the page, then select the Extra 300SX
when the airplane page opens. A “Tech
Notice” box indicates corrected or
updated technical information.
ADDITIONAL ITEMS REQUIRED
Radio System
The Extra 300 can become airborne with any 4-channel
radio system, but to take advantage of its sport ying
and/or 3D capabilities a modern computer radio with
standard features such as a timer, channel mixing, dual
rates and exponentials is required. The Tactic TTX650 or
TTX850 are both viable options that  t this criteria:
❑ Tactic TTX 650 6-channel SLT computer transmitter
(TACJ2650)
❑ Tactic TTX 850 8-channel SLT computer transmitter
(TACJ2850)
❑ Tactic TR624 6-Channel SLT Receiver (TACL0624)
❑ Batteries for transmitter: Hobbico HydriMax
NiMH 4-Cell 4.8V 2000mAh Flat AA receiver pack
(HCAM6321) Duratrax Onyx AA Alkaline Battery OR
(4-pack, DTXP4704)
LiPo Battery
The Extra was primarily designed as a 3D-capable aircraft
with a 3S 1800mAh LiPo. A 3S 2200mAh LiPo is also
suitable, but the additional weight of a heavier battery may
detract from its 3D performance slightly. In any case, if
you start experimenting with batteries and propellers, be
certain you don’t exceed the ESC’s maximum 30A rating.
❑ 3S 11.1V 1800mAh 30C LiPo (GPMP0855)
❑ 3S 11.1V 2200mAh 30C LiPo (GPMP0861)
❑ For additional batteries, adhesive-back hook-&-loop
Velcro is also recommended (GPMQ4480)
LiPo Charger
The bare minimums to look for in a charger are LiPo
balancing and the ability to charge at a minimum rate of
1C. An LED readout and AC capability are also convenient
features. The Great Planes Triton EQ AC/DC charger meets
all the above:
❑ GPMM3155 Great Planes ElectriFly Triton EQ AC/DC
Charger
ORDERING REPLACEMENT PARTS
Before starting to build, inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not
of acceptable quality, or if you need assistance with assembly,
contact Product Support.
Flyzone Product Support
3002 N. Apollo Drive, Suite 1 Ph: (217) 398-8970, ext. 5
Champaign, IL 61822 Fax: (217) 398-7721
E-mail:
airsupport@ yzoneplanes.com
REPLACEMENT PARTS LIST
ORDER NO.
FLZA6214
FLZA6620
FLZA6621
FLZA6622
FLZA6623
FLZA6624
FLZA6625
FLZA6626
FLZA6627
FLZA6628
FLZA6629
FLZA6630
FLZA6631
G
P
MG
2005
GPMQ6600
DESCRIPTION
Propeller Adapter 4mm Shaft
Fuselage
Wing
Tail Surfaces
Cowl
Landing Gear
Landing Gear Covers
Wheel Pants
Canopy/Hatch
Spinner
Tail Wheel Assembly
Servo
Wing Bolt
35mm 1000kV 77g Outrunner Motor
10x4.5 Power Flow Propeller (2)
