H67S Series

Motherboard

User’s Manual

Statement:

This manual is the intellectual property of Foxconn, Inc. Although the information

in this manual may be changed or modied at any time, Foxconn does not obligate

itself to inform the user of these changes.

Trademark:

All trademarks are the property of their respective owners.

Version:

User’s Manual V1.0 for H67S Series motherboard.

PN: 3A222ND00-000-G

Symbol description:

Caution : refers to important information that can help you to use motherboard

better, and tells you how to avoid problems.

Warning : indicating a potential risk of hardware damage or physical injury may

exist.

WEEE:

The use of this symbol indicates that this product may not be treated as household

waste. By ensuring this product is disposed of correctly, you will help prevent potential

negative consequences for the environment and human health, which could otherwise

be caused by inappropriate waste handling of this product. For more detailed

information about recycling of this product, please contact your local city ofce, your

household waste disposal service or the shop where you purchased this product.

More information:

If you want more information about our products, please visit Foxconn’s

website: http://www.foxconnchannel.com

All trade names are registered trademarks of respective manufacturers listed.

All images are for reference only, please refer to the physical motherboard for specic features.

Produkt Specifikationer

Mærke:	Foxconn
Kategori:	Bundkort
Model:	H67S
Bredde:	- mm
Dybde:	- mm
Antal HDMI-porte:	1
Ethernet LAN-porte (RJ-45):	1
Antal USB 2.0-porte:	6
Udgange til hovedtelefoner:	1
Lyd-output kanaler:	7.1 kanaler
Strømkilde type:	ATX
Maksimal intern hukommelse:	16 GB
On-board grafikkort:	Ja
Mikrofonindgang:	Ja
Processorproducent:	Intel
Antal VGA-porte (D-sub):	1
Ethernet-grænsefladetype:	Gigabit Ethernet
Komponent til:	PC
Grafikadapter:	HD Graphics
Netværksfunktioner:	Gigabit Ethernet
Antal PS/2-porte:	1
Processor sokkel:	LGA 1155 (Socket H2)
PCI Express x16 slots:	1
Understøttelse af parallel behandlingsteknologi:	Ikke understøttet
Kompatibel processor serie:	Intel Core i3, Intel Core i5, Intel Core i7
Bundkort chipset familie:	Intel
Bundkort chipsæt:	Intel® H67
Understøttede hukommelsestyper:	DDR3-SDRAM
Antal hukommelsesstik:	2
Understøttede hukommelsesclock-hastigheder:	1066,1333 MHz
Antal SATA III-stik:	2
Hukommelseskanaler:	To-kanals
USB 2.0-stik:	2
S/PDIF-udgangsstik:	Ja
CPU-ventilatorstik:	Ja
Antal COM-stik:	1
ATX strømstrik (24 stikben):	Ja
Antal kabinetventilatorstik:	2
Lydstik på frontpanel:	Ja
Antal SATA II stik:	1
Motherboard form faktor:	mini ATX
Understøttede lagerdrev brugerflader:	SATA II, SATA III
BIOS-hukommelsesstørrelse:	64 Mbit
Antal eSATA-porte:	1
Strømstik til ventilator:	Ja
Grafikadapter familie:	Intel
Understøttede processor systembusser:	1333 MHz
