COMPONENT SPEAKER SYSTEMS

 CS-CM50 CS-CM60

PeakPower(Watts) 220 240

RatedPower(Watts) 35 40

FrequencyResponse 41Hz-26kHz 35Hz-26kHz

Impedance 4Ohms 4Ohms

Sensitivity 85dB 86dB

ConeMaterial Polypropylene Polypropylene

Tweeter PEI PEI

MountingDepth 43mm(1-11/16”) 45.5mm(1-13/16”)

MountingDiameter 118mm 126mm

 (4-21/32”) (5”)

CS-CM50 CS-CM60

WARNING:Donotdrillmountingholeswithspeakerinplaceasthiscouldallowdrillshavingstodamagethe

voicecoilandvoidyourwarranty.

SPEAKER PARAMETERS

www.fusionelectronics.com

TWEETER

Ø53mm

(2-1/16”)

9mm(11/32”)

20mm(25/32”)

47mm

(1-27/32”)

INSTALLATION GUIDELINES

Ensuretheaudiosystemisturnedoffbeforemakinganyconnections

totheamplier,speakersorsourceunit.Failuretodosocouldresultin

permanentdamagetotheaudiosystem.

Whenwiringthespeakersensurethatthewireisprotectedfromsharp

objectsandalwaysuserubbergrommetswhenwiringthroughmetal

panels.Ensureallterminalsandconnectionsareprotectedfromthe

vehiclechassisandfromeachotherasfailuretodosocouldresultin

permanentdamagetotheaudiosystem.

Whenconnectingthesourceunitandspeakersensureyouconnect

thepositiveandnegativeoutputwirefromthesourceunittothe

correspondingspeakerterminals.Thiswillensuretheaudiosystemwill

beinphase.



1) Ensurethereisadequateclearance&depthforthespeakertobe

 mounted

2) Usethesuppliedtemplatetomarkout&cutthecorrectdiameterhole

3) Drillfourholesforthemountingscrews

4) Seperatethegrillefromtheframe

5) Insertthespeaker&grilleframeandafxwiththescrewsprovided

6) Completeinstallionbyreplacingthegrilleintothegrilleframe

TWEETER (Surface/Angle mount)

To obtain the best performance from the tweeter it should be located on axis to approximately 4” below the rear

view mirror. Select the mount you require and use this as a template to drill the holes to mount or alternatively

if using an adhesive pad ensure the mounting surface is cleaned with a residue free cleaner and stick the

tweeter down. Attach the wires to the speaker terminals.

TWEETER (Flush mount)

Ensure you have adequate depth to mount the tweeter and cut a 47mm hole. Assemble the rear mount with the

spring clamp and press through from the rear of the hole, then attach the front plate to the rear plate as shown

in the illustration. Attach the wires to the speaker terminals.

YOU CAN HELP PROTECT THE ENVIRONMENT! Please remember to respect the local regulations: Hand in the non-working electrical equipment to an appropriate waste disposal center.
