Side 1/5

XS Series Speakers Installation Instructions .................................................................................... 2

Instructions d'installation des haut-parleurs XS Series ..................................................................... 6

Altoparlanti XS Series Istruzioni di installazione ............................................................................. 11

Lautsprecher der XS Series – Installationsanweisungen ................................................................15

Instrucciones de instalación de los altavoces de la XS Series ....................................................... 19

Instruções de instalação dos alto-falantes XS Series ..................................................................... 23

XS Series luidsprekers installatie-instructies .................................................................................. 27

Garmin®, the Garmin logo, FUSION®, the Fusion logo, and True-Marine™ are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. These trademarks may not be used

without the express permission of Garmin.

October 2018

190-02481-90_0A

XS Series Speakers Installation

Instructions

Important Safety Information

WARNING

Failure to follow these warnings and cautions could result in

personal injury, damage to the vehicle or vessel, or poor product

performance.

This device must be installed according to these instructions.

Disconnect the vehicle's or vessel's power supply before

beginning to install this product.

CAUTION

Continuous exposure to sound pressure levels over 100 dBA

may cause permanent hearing loss. The volume is typically too

loud if you cannot hear people speaking around you. Limit the

amount of time you listen at high volume. If you experience

ringing in your ears or muffled speech, stop listening and have

your hearing checked.

Always wear safety goggles, ear protection, and a dust mask

when drilling, cutting, or sanding.

NOTICE

When drilling or cutting, always check what is on the opposite

side of the surface.

It is strongly recommended that you have your audio system

installed by a professional installer to ensure optimum

performance.

You must read all installation instructions before beginning the

installation. If you experience difficulty during the installation, go

to for product support.www.fusionentertainment.com

What's In the Box

• 2 speakers

• 12 Phillips stainless steel mounting screws

◦ 4 in. models: 3.5 mm x 25.4 mm (6 gauge x 1 in.)

◦ 6.5 in. and 7.7 in. models: 4.2 mm x 25.4 mm (8 gauge x 1

in.)

• Mounting template

• Speaker grilles

Tools Needed

• Electric drill

• Drill bit (size varies based on surface material)

• Phillips screwdriver

• Wire strippers

• Crimping tool

• Electrical tape

• Appropriate saw or utility knife to cut surface material

• Marine sealant (optional)

NOTE: For customized installations, additional tools and

materials may be needed.

Mounting Considerations

NOTICE

When mounting the speaker in an area exposed to weather or

water, you must mount the speaker on a vertical surface. If you

mount the speaker on a horizontal surface facing up, water can

gather in and around the speaker, causing damage over time.

Selecting the correct mounting location is critical to optimize the

performance of each speaker. FUSION® speakers are designed

to perform in the widest possible range of mounting locations,

but the more you plan the installation, the better the speakers'

sound will be.

• For the best performance, you should mount the speakers

higher in the boat. Sound travels in the direction in which the

speakers are facing, so if you mount them in a lower location,

the sound quality and volume may not be not ideal.

• If you intend to mount the speakers outside the boat, you

must mount them in a location well above the waterline,

where they are not submerged or damaged by docks, pilings,

or other pieces of equipment. When mounted correctly, these

speakers are rated IP65 for protection from the front of the

speaker. Water exposure and damage to the rear of the

speaker voids the warranty. This includes situations when the

speakers are mounted in a sealed enclosure, especially if

they are exposed to wash down. Using an enclosure with a

port or vent exposed to the outside environment may allow

water to collect and damage the speaker.

• You should select mounting locations that enable you to hear

sound from both speakers at the same time to achieve a

sound stage effect. To achieve this effect, you should not

mount the speakers side-by-side.

• When possible, you should select mounting locations where

the area behind each speaker is enclosed.

• You must select mounting locations that provide sufficient

clearance for the mounting depth of the speakers as

specified in the product specifications.

• For better bass performance, you should select mounting

locations that provide the appropriate space behind the

speaker according to the optimum enclosure design

requirements in the specifications section. Too small an area

restricts bass, and too large an area compromises bass

performance. Also, mounting a speaker close to an open

area (where sound from the back of the speaker has a very

short path to compete with sound from the front of the

speaker) produces the least bass.

• When a speaker is not exposed to the outside environment,

you can achieve a better bass performance using an

enclosure with a ported design.

• You can reference the Thiele Small (T/S) parameters in the

specifications section when designing a custom enclosure for

the speakers.

• You should select a flat mounting surface for the best seal.

• You should protect the speaker wires from sharp objects and

always use rubber grommets when wiring through panels.

• You should select mounting locations that avoid potential

obstacles, such as fuel and hydraulic lines and wiring.

• You should protect all terminals and connections from

grounding and from each other. Failure to do so could result

in permanent damage to the audio system and void the

product warranty.

• To avoid interference with a magnetic compass, you should

not mount the speakers closer to a compass than the

compass-safe distance value listed in the product

specifications.

• You must turn off the audio system before making any

connections to the source unit, amplifier, or speakers. Failure

to do so could result in permanent damage to the audio

system.

Mounting the Speakers

Before mounting the speakers, you must choose a location

following the guidelines above.

Before cutting the mounting surface you should verify that there

is enough clearance for the speaker behind the surface. Refer to

the specifications for clearance information.

2 Installation Instructions
