Side 1/4
Install Instructions for:
CM52-BGM-II, CM52s-BGM-II, CM62-BGM-II, and CM82-BGM-II
CM-BGM-II Series
by
Box Contents
1 Speaker
1 Flexible conduit clamp
1 Cover plate
1 Magnetic Grille
Tile bridge
Bafe
Magnetic Grille
Speed Wing™ mounting arms
Flexible conduit clamp
Secondary attachment point
Cover plate
© 2020 MSE Audio, and SoundTube Entertainment, Inc. All rights reserved. PN INS-CM-BGM-II | Rev 07.02.2020
UL Listed _____________
1.855.663.5600
|
www.soundtube.com
Do not spec or install speaker near support beam, ventilation duct or
other structure that may interfere with speaker function or dispersion.
Warning/Avertissement Warning/Avertissement
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for
optimum audio performance, installer must follow all directions issued by SoundTube Entertainment.
Les haut-parleurs SoundTube doivent être installés par un installateur audio professionnel ou un
entrepreneur. Pour des raisons de sécurité et de performances audio optimales, l'installateur doit suivre
toutes les instructions émises par SoundTube Entertainment.
N'installez pas à proximité d'une poutre de support, d'un conduit de
ventilation ou d'une autre structure susceptible d'interférer avec la
fonction ou la dispersion des enceintes.
Grille safety restraint
ceiling tile
tile bridge
T-bar
hole for speaker
1. Unpack speaker & set aside
grille assembly.
2. Use included tile bridge to
mark a circle in the tile. Use
Rotozip or other tool to cut hole,
and remove cutout portion.
3. Place tile bridge into ceiling
grid, then replace ceiling tile.
8. Select the tap position by
adjusting rotary switch
to desired high impedance
value or voice coil direct mode.
11. Done!10. Place grille onto bafe. (The
grille is held in place by magnets
in the bafe.)
6. Insert speaker into mounting
hole . Screw down both bolts on
the bafe face to actuate the
mounting wings. Firmly secure
both bolts – do not over-tighten.
7. If required, a sheet-metal tab
located on the rear panel of the
speaker serves as a secondary
point of attachment (cable not
included).
Hole Diameter:
266.7 mm (10.50 in)
5. Tighten screw on terminal
plate, and push conduit
connector into knockout.
4. Run signal wires through
conduit connector, then through
cover plate. Connect to ceramic
terminal strip. Two + and two -
connectors are provided for
daisy chaining.
1.
2.
9. Attach grille safety clip by
placing the large end of the clip
over snap-t post (1), then
sliding clip until small end snaps
into place around post (2).
1.855.663.5600
|
www.soundtube.com
Drop Tile Install Instructions for:
CM52-BGM-II, CM52s-BGM-II, CM62-BGM-II, and CM82-BGM-II
CM-BGM-II Series
by
