Applicable systems: Futaba T-FHSS Air-2.4GHz system transmitter

R3006SB T-FHSS Air-2.4GHz Bidirectional Communication System

S.BUS2 / S.BUS Port and 6 Channels for Conventional System Receiver

Compliance Information Statement

(for U.S.A.)

This device, trade name Futaba Corporation, model number R3006SB, complies with

part15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may

cause undesired operation.

CAUTION:

To assure continued FCC compliance:

$Q\FKDQJHVRUPRGL¿FDWLRQVQRWH[SUHVVO\DSSURYHGE\WKHJUDQWHHRIWKLVGHYLFHFRXOG

void the user's authority to operate the equipment.

 7KLV HTXLSPHQW FRPSOLHV ZLWK )&& UDGLDWLRQ H[SRVXUH OLPLWV VHW IRUWK IRU DQ

uncontrolled environment.

7RPHHWWKH5)H[SRVXUHUHTXLUHPHQWVRIWKH)&&WKLVGHYLFHVKDOOQRWEHFRORFDWHGZLWK

another transmitting device.

The responsible party of this device compliance is:

Futaba Service Center

3002 N Apollo Drive Suite 1, Champaign, IL 61622 U.S.A.

7(/RU(PDLOIXWDEDVHUYLFH#KREELFRFRP6XSSRUW

5 % ÀS Speci cations

T-FHSS Air-2.4GHz system/S.BUS2 and S.BUS port and 6 channels for

conventional system receiver

• Dual antenna diversity

• Size: 1.7 x 0.98 x 0.35 in. (43.1 x 25.0 x 8.8 mm)

• Weight: 0.3 oz. (8.5g)

• Power requirement: 4.6V to 7.4V

• Battery F/S Voltage: It sets up with a transmitter

* Be sure that the battery is the correct size for the amount and type of servos

being used. When using a BEC, be sure that it is capable of delivering constant

voltage and can accept enough current that will be used by the RX and servos.

Do not use a dry cell battery with this system.

Thank you for purchasing a Futaba R3006SB T-FHSS Air-2.4GHz compatible receiver. The R3006SBUHFHLYHUIHDWXUHVELGLUHFWLRQDOFRPPXQLFDWLRQ

with a T-FHSS Air-2.4GHz Futaba transmitter using the S.BUS2 S.BUS2 port. Using the port an impressive array of telemetry sensors may be utilized.

It also includes both standard PWM output ports and S.BUS output ports.

LED Indication

Green Red Status

Off Solid No signal reception

Solid Off Receiving signals

Alternate blink Unrecoverable error (EEPROM, etc.)

(Antenna installation)

90˚

Please refer the table below

for LED status vs receiver's

condition.

1M23N17485

6%86

SRUW

6%86SRUW

6%ك

6%%ك

6%866HUYR

6%86*\UR

0RGHVZLWFK

$QWHQQD

/('

6HUYRIRU FRQYHQWLRQDO

V\VWHP

&KDQQHORXWSXW

&KDQQHORXWSXW

%DWWHU\WR6%%

56% 7HOHPHWU\6HQVRU

6%86+8%

7HOHPHWU\6HQVRU

,WVQHFHVVDU\WRFKDQJHLWWR

0RGH%6%86

Usage precaution

• Futaba T-FHSS Air system does not work with current Futaba T-

FHSS / S-FHSS / FHSS / FASST / FASSTest system.

• The R3006SB receiver can only be used with T-FHSS Air capable

transmitters.

WARNING

Changes or modification not expressly approved by the party

responsible for compliance could void the user’s authority to operate the

equipment.

The R3006SB receiver should be protected from vibration by foam

rubber, Velcro or similar mounting methods. Protect from moisture.

Keep away from conductive materials to avoid short circuits.

Antenna installation precaution

Don't cut or bundle the receiver antenna wire.

Don't bend the coaxial cable. It causes damage.

The antennas must be mounted in such a way to assure they are

strain relieved.

Keep the antenna as far away from the motor, ESC and other noise

sources as you possibly can.

Be sure that the two antennas are placed at 90 degrees to each other.

• The R3006SB has two antennas. In order to maximize signal reception

and promote safe modeling Futaba has adopted a diversity antenna

system. This allows the receiver to obtain RF signals on both antennas

and ﬂy problem-free.

Antenna installation for carbon fuselage

WARNING

You must leave 30mm at the tip of the antenna fully exposed. The ex-

posed antenna should be secured so that it cannot move around or back

inside of your aircraft.

S.BUS2 precaution

DANGER

Don't connect a connector, as shown right.

• It will be a short-circuit, if it connected in

this way. A short circuit across the battery

terminals may cause abnormal heat, fire

and burning.

Don't connect servo for conventional system to S.BUS/S.BUS2 port.

• Digital servo for conventional system→ It does not operate.

• Analog servo → It may cause abnormal heat, ﬁre and burning.

WARNING

Only S.BUS2 capable devices may be connected the S.BUS2 port.

Standard S.BUS servos and gyros should not be connected the S.BUS2

port.

(Typical installation)

5HFHLYHU

DANGER

Do not insert either a switch

or battery in this manner.
