Side 1/3

Rev.D

INST-715

required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications

Product Mounting Disclaimer

Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage

of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson

products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is

and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.

PS-004

7160-0821, 7160-0821-01

Form

INSTALLATION INSTRUCTIONS

Product Revision

If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868

Ford Utility Police Interceptor Close-To-Dash Mount

Printing Spec:

•You must read and follow all of these installation instructions. Failure to follow the installation

instructions may result in serious bodily injury or death

•DO NOT install or use this assembly in the area in which the airbag on the vehicle may be

deployed. The installer and user of this assembly are responsible for installing and using this

assembly outside the area in which an airbag may be deployed. (See Product Mounting

Disclaimer Below)

•If the installation of the equipment requires that the equipment (or any additional equipment

that is added to the installation) be placed in front of an airbag, the airbag should be

deactivated. In order to secure permission for deactivating the airbag you must contact the

National Highway Traffic Safety Administration at 1-800-424-9393 to gain permission to do so.

If you have any questions or need assistance, call Gamber-Johnson at 1-800-456-6868.

•High speed vehicle turns may cause parts fo the assembly to swivel, interfering with the driver

or other equipment.

•Keep these installation instructions with the product and readily available in the vehicle

for future reference of other users of the product.

•Additional copies of the installation instruction can be obtained from Gamber-Johnson.

If you need assistance or have any questions, go to www.gamberjohnson.com or

call Gamber-Johnson at 1-800-456-6868.

•DO NOT remove the warning label from the product under any circumstances.

1/3

factory dash

cover panel

plastic clips

The Ford Utility Police Interceptor Close-To-Dash mount is designed

specifically to mount on a Gamber-Johnson vehicle specific console box

(7160-0412) and to attach to the dash of the Ford Utility.

metal dash

cover panel

2/3

Installing the mount:

Step 1. Remove the dash cover panel using an 8mm hex socket.

Step 2. Remove the (4) plastic clips from the bottom side of the cover panel.

Step 3. Attach the (4) plastic clips (removed in step 2) to the new metal Dash cover

panel.

Step 4. Attach the metal dash cover panel using the same bolt that was removed

in step 1. Tighten bolt to a snug fit only. Over torquing will cause the U-Nut to

strip.

Produkt Specifikationer

Mærke:	Gamber-Johnson
Kategori:	Ikke kategoriseret
Model:	7160-0821-01
Bredde:	482.6 mm
Dybde:	457.2 mm
Højde:	374.7 mm
Vægt:	5440 g
Produktfarve:	Sort
Materiale:	Stål
