PS-001
INSTALLATION INSTRUCTIONS
1500 & 1500SSV - 2011+
Printing Spec:
Product Form Revision
If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868
LEG KIT - CHYRSLER/DODGE - RAM -
7160-0422
M8 threaded hole thru hole
thru holethru holethru hole
2. Assemble 1/4-20 x 2.00" Button Head
Screw, jam nut and Clamp Plate to
Front Leg as shown above.
Insert tab on Front Leg into thru hole
as shown in photo.
1/2
1. Remove center seat section and
seat brackets.
Note the mounting points for the
Front Leg - a M8 threaded hole toward
the drivers side, a thru hole toward the
passengers side (under carpet).
Rear Leg
Clamp Plate
Button Head Screw
Tab
Front Leg
1/4-20 x 2.00 Socket
Jam Nut
