Side 1/9

7160-0336 Upper Shelf Assembly

7160-0020 Lower Shelf Assembly

INSTALLATION INSTRUCTIONS

Product Revision Form

If you need assistance or have questions, call Gamber-Johnson at 1-800-456-6868

Dodge Charger Trunk Shelf 2011+

Rev. C

INST-527

Printing Spec: PS-001

Product Mounting Disclaimer

Gamber-Johnson is not liable under any theory of contract or tort law for any loss, damage, personal injury, special, incidental or consequential damages for personal injury or other damage

of any nature arising directly or indirectly as a result of the improper installation or use of its products in vehicle or any other application. In order to safely install and use Gamber-Johnson

products full consideration of vehicle occupants, vehicle systems (i.e., the location of fuel lines, brakes lines, electrical, drive train or other systems), air-bags and other safety equipment is

required. Gamber-Johnson specifically disclaims any responsibility for the improper use or installation of its products not consistent with the original vehicle manufactures specifications

and recommendations, Gamber-Johnson product instruction sheets, or workmanship standards as endorsed through the Gamber-Johnson Certified Installer Program.

These instructions describe installing 7160-0336 Upper Shelf Assembly and 7160-0020 Lower Shelf Assembly

in 2011 and newer Dodge Charger vehicles.

The units can be installed individually or as a set.

1 of 9

7160-0020

Lower Shelf Assembly Installed

7160-0336

Upper Shelf Assembly Installed

2 of 9

Parts Lists

7160-0336 Upper Trunk Shelf - Dodge Charger 2011+

36"

13351

13340

13341

14377

14378

14379

14380

14381

14382

EDGE TRIM

RH DRAWER SLIDE

LH DRAWER SLIDE

LH SIDE MTG BRACKET

RH SIDE MTG BRACKET

UPPER TRAY

VERTICAL BRACKET

LH SLIDE STOP

RH SLIDE STOP

QTY

PART NO.

DESCRIPTION

7120-0541 Hardware Bag - Upper Trunk Shelf

13349-0001

13350-0001

1173-1412

1503-1400

NYLOK NUT M10-1.5

WASHER FLAT M10 STEEL ZINC PLT

HEX HD MS .25-20UNC x .75 LG

NYLOK NUT .25-20UNC

QTY

PART NO.

DESCRIPTION

1 7120-0541

HARDWARE BAG - UPPER TRUNK TRAY

7160-0020 Dodge Charger Lower Trunk Shelf

13336

13339

13342

7120-0385

7130-0069

LOWER TRAY

SLIDE MTG BRACKET

HARDWARE BAG - LOWER TRUNK TRAY

RH SLIDE ASSEMBLY w/ STUDS

QTY

PART NO.

DESCRIPTION

7130-0070

LH SLIDE ASSEMBLY w/STUDS

7120-0385 Hardware Bag - Lower Trunk Shelf

32"

12079-0005

13238-0001

13349-0002

13350-0002

13351

13352-0001

13353

13354

1173-1412

WASHER .25 EXT TOOTH

WASHER .44 FLAT

NYLOK NUT M12-1.75

WASHER M12 FLAT

EDGE TRIM

CARRIAGE BOLT .44-14 x 8.5"

WING NUT .44-14

VINYL CAP BLACK

.25-20UNC x .75 HEX HD SCREW

QTY

PART NO.

DESCRIPTION

4 1403-1400

.25-20UNC HEX NUT

6 1503-1400

NYLOK NUT .25-20UNC

11043-0001

.25 SELF-DRILLING SCREW

Produkt Specifikationer

Mærke:	Gamber-Johnson
Kategori:	Ikke kategoriseret
Model:	7160-0336
Produktfarve:	Sort
Materiale:	Aluminium
Monteringstype:	Gulv
Kapabilitet:	Dodge Charger Police Vehicle (2011-2013)
Antal produkter inkluderet:	1 stk
Dybde (efter britisk standard):	21.7 "
Højde (efter britisk standard):	6.8 "
Bredde (efter britisk standard):	48.9 "
Vægt (efter britisk standard):	27.5 Pund
Justerbar:	Ingen
