FAN COIL THERMOSTAT PLACEMENT

In order to mount FC100 to the wall, separate the upper case from the

lower case with the help of a screwdriver from the places shown

below.

Fan Coil Thermostat needs to be placed in the room which is used

most frequently. For instance; living room or lounge.Placing the Fan

Coil Thermostat in a spot that have air circulation like entrance of a

room or side of window should be avoided. Also anywhere close to

heating units such as radiator, stove and spots which get direct sun

lights would not be suitable.Fan Coil Thermostat needs to be located

above the ﬂoor 150 cm height. Few trials may be made to ﬁnd the

most convenient spot.

FAN COIL THERMOSTAT WIRING DIAGRAM

GENERAL SPECIFICATIONS

FC100 is a digital fan coil thermostat. The user can adjust the Fan Coil

Thermostat with the required temperature and fan speed to get more

comfortable and economic heating/cooling.

 For 2 pipe fan coil systems User Friendly Interface

 Manual heating and cooling option 3 Stage Fan Speed

FC100 AND EQUIPMENTS

TECHNICAL DATA

FAN COIL THERMOSTAT

90mm / 145mm / 29.8mm

110-220V AC 50/60 Hz

8A (250VAC – Resistive Load)

8A (30 VDC – Resistive Load)

0.1 C

0.5 C

o o

(5 C) – (35 C)

o o

(-10 C) – (+50 C)

o o

(-20 C) – (+60 C)

Dimensions

Operating Current

Relay NO Switching Current

Temperature Measurement Accuracy

Operating Sensivity

Operating Temperature Range

Operating Temperature

Storage Temperature

FC100 Fan Coil Thermostat

Dowels and Screws

ENGLISH

FC100 USER MANUAL

generallife.com.tr

DIGITAL FAN COIL THERMOSTAT

150 cm

min.20 cm

Fan Speed Adjustment Button

High Fan Speed Symbol

Medium Fan Speed Symbol

Low Fan Speed Symbol

ON/OFF and Mode Select Button

Cooling Mode Symbol

Off Symbol

Heating Mode Symbol

Temperature Dial Line

Temperature Adjustment Knob

LOW

MED

HIGH

AC 220V

VALVE

FAN

OFF

generallife.com.tr

FC100

USER MANUAL

DIGITAL FAN COIL THERMOSTAT

DECLARATION OF CONFORMITY

ISIPARK İÇ VE DIŞ TİC. İNŞ. ISITMA SİSTEMLERİ OTO. SAN.A.Ş.which

Head Oﬃce and production site is located on Fatih Mah. 1188

Sk.No:13/A Sarnıç - Gaziemir - İZMİR – TÜRKİYE declares that the

product marked with CE and its speciﬁcations below is covered by the

provisions of the mentioned directive.

Brand

Product Name

Product Type

Compatible Directives:

Electromagnetic Compatibility Regulation 2014/30/EU

(EMC EN 61000-6-3: 2007 + A1: 2011, EN 61000-6-1: 2007)

Low Voltage Directive 2014/35/EU

(LVD EN 60730-2-9:2010, EN 60730-1:2011)

Additional Information: The mentioned product can be used with 2

pipe fan coil systems and compliance with the directives only covers

the product. ISIPARK is not responsible for the entire system's

compliance with the directives. This statement is not valid if changes

are made to the product without our approval.

WARRANTY CONDITIONS

1- The warranty period starts from the invoice date and warranted

against manufacturing defects for 5 years.

2-Devices and apparatuses are delivered to the customer in working

condition in our company. On-site commissioning is subject to a

service fee.

3-The repair of the devices and apparatuses are covered by the

warranty is carried out in our company factory and should send by

contracted transportation company. In on-site services, the

transportation and accommodation expenses of the service

personnel belong to the customer. The shift fee during transportation

is added to the service fee and collected in advance.

4-The maintenance of devices and apparatuses are done in our

company. For the maintenance of the devices and apparatuses, the

round travel fares belongs to the customer.

5-In case of malfunctioning of the devices and apparatuses whose

warranty period continues, it is tested in our company whether the

malfunction is caused by a customer or manufacturer fault, and it is

reported with a report issued by our company.

6-In case of detection of manufacturer-induced errors of devices and

FAN COIL THERMOSTAT WORKING LOGIC

Heating Mode

Your Fan Coil Thermostat measures the temperature of its

environment every 5 seconds. If the ambient temperature rises 0.5

degrees above the temperature you have set, your Fan Coil

Thermostat will stop the operation of fan coil unit, if it falls below 0.5

degrees, it initiates the operation of fan coil unit. Thus, it ensures that

the ambient temperature remains within a certain range.

Cooling Mode

Your Fan Coil Thermostat measures the temperature of its

environment every 5 seconds. If the ambient temperature rises 0.5

degrees above the temperature you set, your Fan Coil Thermostat will

initiate the operation of fan coil unit, if it falls below 0,5 degrees,it

stops the operation of fan coil unit. Thus, it ensures that the ambient

temperature remains within a certain range.

Time

Heating

Unit Off

Heating

Unit On

Set

Temperature

Room

Temperature

22.0 C

22.5 C

21.5 C

: GENERAL Life

: FC100

: Digital Fan Coil Thermostat

apparatuses whose warranty period continues, the customer can

request a replacement or repair of the devices and apparatuses at full

expense by the manufacturer, unless it's higher than the product's

price

7-In the event that the faults of the devices and apparatuses whose

warranty period continues are determined as caused by the customer,

all expenses would be belong to the customer.

8-Customers should be aware of damages (if there is any) of product

and warn manufacturer since the day warranty duration starts.If

customer do not warn manufacturer with knowledge of damage,

customer lose the rights of article 6.

9-Malfunctions resulting from the use of devices and apparatuses

contrary to the matters stated in the User Manual are not covered by

the warranty.

10-Devices and their apparatuses are out of warranty if they are

beaten, broken or scratched by the customer.

11-Damages resulting from the use of devices and apparatuses

belonging to other brands and models without the approval of the

manufacturer are not covered by the warranty.

12-Errors that may occur due to rust, oxidation and liquid contact

working in acidic / humid environments are not covered by the

warranty.

13-Damages that may occur during the transportation of devices and

apparatuses are not covered by the warranty. Customers can take a

transportation insurance.

14-Damages caused by mains voltage / faulty electrical installation

are not covered by the warranty.

15-Devices and apparatuses are out of warranty for malfunctions

caused by force majeure such as ﬁre, ﬂood, earthquake etc.

16-All of the devices and apparatuses, including all their parts, are

under the warranty of our company.

17-In case of malfunction of the devices and apparatuses within the

warranty period, the time spent during repairment period is added to

the warranty period. The repair period of the product cannot exceed

20 working days. This period starts from the date of notiﬁcation to the

service station of the malfunction related to the product or, in the

absence of a service station, to the seller, dealer, agency,

representative, importer or manufacturer of the product. Consumer

can report the problem by; phone, fax, e-mail, registered and reply paid

letter or a similar way. However,in case of a conﬂict , responsibility of

prove is belong to the customer. If the malfunction of the product is

not repaired within 20 working days, the manufacturer-producer or

importer; has to allocate another product with similar features to the

use of the consumer until the repair of the product is completed,

18- Although the consumer uses his/her repair rights,

-If the product breaks down for 4 times in a year or 6 times in warranty

duration and these problems effects main purpose of the product.

(starting from delivery time during warranty.)

- Exceeding the maximum time required for repair,

- In the event that the service station is not available, if it is determined

that the repair of the defect is not possible with the report prepared (in

order) by one of the seller, dealer, agency, representative, importer or

manufacturer, a refund or a price discount at the rate of defect can be

requested.

19-The customer can make complaints and appeals to consumer

courts or consumer arbitration committees.

20-The warranty document must be kept by the customer during the

warranty period. If the document is lost, a second document will not

be issued. In case of loss, repair and replacement of devices and

apparatuses will be made for a fee.

4 55 6 7

ISIPARK reserves the rights of changing product speciﬁcations and

user manuals.

*For all changes, you may visit generallife.com.tr

WARRANTY CERTIFICATE

Vendor

Title:

Adress:

Tel: Fax:

E-

Mail: Invoice Date and Number:

Delivery Time and Place:

Authorised Signatory:

Company Stamp:

Product

Type: Digital Fan Coil Thermostat

Brand: GENERAL Life

Model: FC100

STAMP

Time

Cooling

Unit Off

Cooling

Unit On

Set

Temperature

Room

Temperature

22.0 C

22.5 C

21.5 C

ENGLISH

FC100 USER MANUAL

generallife.com.tr

DIGITA L FAN COIL THE RMOS TAT

Manufacturer

Title: ISIPARK İÇ DIŞ TİC. A.Ş.

Adress: Fatih Mah. 1188 Sk. No:13/A Sarnıç

Gaziemir İzmir-TÜRKİYE

Tel: +90 (232) 457 99 50

Fax: +90 (232) 457 91 22

E-mail: generallife@generallife.com.tr

Authorised Signatory:

Company Stamp:

Product

Type: Digital Fan Coil Thermostat

Brand: GENERAL Life

Model: FC100

Guarantee Period: 5 Years

Max. Time to Repair: 20 Days

Banderole and Serial Number:

V-01.2021
