Side 1/2

GIRA

Info

Presence detector extension unit insert

Installation Instructions

Presence detector extension unit insert 16/02 Page: 1 of 2

System 2000

Presence detector extension unit insert Order No.: 0335 00

Function

Presence detector extension unit insert as a 3-wire extension unit (active extension) for presence

detectors or automatic switches.

The extension unit can only be used in conjunction with the presence detector attachment or

automatic switch attachment. Other attachments than those specified do not yield any meaningful

functions.

In conjunction with the presence detector attachment or the automatic switch attachment unit, the 3-

wire extension unit transmits a light-independent switching signal to the main unit when a movement is

detected. The locking time of the 3-wire extension unit is approx. 3 secs. The signals are processed in

the attachment (presence detector or automatic switch attachment) of the main unit.

Inserts that can be used for the main unit:

Universal dimmer, LV dimmer

Triac-switching insert, Tronic-switching insert

Relay insert

Note:

The extension unit is not suitable for direct switching of loads.

The extension unit must not be used in conjunction with more than one main unit.

Fitting instructions

The extension unit insert is installed in a DIN c

49073 flush-mounting box (see fig. A).

The connection terminals of the insert must be at

the bottom (wallmounting).

The attachment d is plugged into the insert

together with frame e.

The electrical contact with the insert is ensured by

plug f.

Connection diagram see fig. B.

Main unit g.

Extension unit h.

Further extension units i.

Load j.

GIRA

Info

Presence detector extension unit insert

Installation Instructions

Presence detector extension unit insert 16/02 Page: 2 of 2

Safety instructions

Attention: Electrical equipment must be installed and fitted by qualified electricians only.

Non-observance of the installation instructions may cause fire and other hazards.

Technical specifications

Nominal voltage: AC 230 V ~, 50 / 60 Hz

N conductor requiered

Connection: to main unit (with presence detector or automatic switch attachment)

The number of parallel

extensions is limited to

5 at maximum: when controlled from a universal dimmer

10 at maximum: when controlled from other flush-mounting inserts

Length of line: max. 100 m

Acceptance of guarantee

We accept the guarantee in accordance with the corresponding legal provisions.

Please return the unit postage paid to our central service department giving a brief description

of the fault:

Gira

Giersiepen GmbH & Co. KG

Service Center

Dahlienstrasse 12

D-42477 Radevormwald

The CE sign is a free trade sign addressed exclusively to the authorities and does not include

any warranty of any properties.

Gira

Giersiepen GmbH & Co. KG

Postfach 1220

D-42461 Radevormwald

Telefon: +49 / 21 95 / 602 - 0

Telefax: +49 / 21 95 / 602 - 339

Internet: www.gira.de

Produkt Specifikationer

Mærke:	Gira
Kategori:	Smart hjem
Model:	033500
Produktfarve:	Metallic
Indbygget skærm:	Ingen
Produkttype:	Koblings-/dæmpningsaktuator
Driftstemperatur (T-T):	-20 - 45 °C
Certificering:	CE
Strømkilde type:	Vekselstrøm
Monteringstype:	Planmonteret
Indgangsspænding:	230 V
Indgangsfrekvens:	50/60 Hz
Indbygget dybde:	22 mm
