Side 1/5

GIRA

Info

Smoke detector

Instructions for Installation

Smoke detector 45/00 Seite: 1 von 5

Smoke detector Art. Nr.: 0869 00 / 04

Product characteristics at a glance

• Battery-operated smoke detector with photoelectric scattered light principle

• Automatic self test of the smoke evaluation

• Ability to link up to 40 smoke detectors

• Loud, pulsing warning signal at approx. 85 dB (A)

• Battery change indicator

• Contamination/disturbance indicator

• Integrated test button for testing the function

• Battery compartment check: if no battery is installed in the smoke detector, it cannot be locked into

the socket

• Polarity reversal protection: the device cannot be destroyed due to incorrect battery connection

• VdS-recognition: G 200 121

Safety Indications

• Never paint over the smoke detector.

• Smoke detectors only detect the smoke of a fire, but not the flames themselves.

• Smoke detectors do not extinguish a fire. When the alarm sounds, search for the source of the fire

and call the fire department if necessary.

• Do not use rechargeable batteries (accumulators) or power packs for power supply. They can

cause disruptions or the premature failure of the device.

• The smoke detector produces a very loud and shrill sound, which can damage hearing. For this

reason, please observe a safety distance of 50 cm during the function test.

• The smoke detector only monitors a defined area in the vicinity of the installation site. Install

enough detectors to cover the entire living area and ensure optimum protection.

• People under the influence of alcohol or drugs may not be awakened by the signal sound.

Installation site

Smoke detectors should preferably be installed outside the door of or in bedrooms so that you will be

awakened by the smoke alarm at night. In buildings with several floors, at least one smoke detector

should be located on each floor.

The smoke detector will have optimum detection characteristics if it is installed under the ceiling in the

center of the room. If this is not possible, keep a distance of at least 50 cm from the wall.

If the smoke detector is installed in the kitchen, you should locate the device as far away from the

cooking zone as possible to prevent false alarms due to steam.

In large houses, you should use several, linked smoke detectors to cover the entire living area. If

smoke is detected by one smoke detector, it sets off an alarm and activates all connected smoke

detectors, which then also sound the alarm. Thus, you will be awakened during the night by your

linked smoke detector in the bedroom if the smoke detector in the cellar detects smoke.

GIRA

Info

Smoke detector

Instructions for Installation

Smoke detector 45/00 Seite: 2 von 5

Minimum protection: one smoke detector in

the hallway or in the stairwell of each floor

Optimum protection: one smoke detector in

each bedroom and living room

Unsuitable installation sites

In order to prevent false alarms and

malfunctions, do not install the smoke detector:

• in rooms where a large amount of steam,

dust, or smoke are produced under normal

circumstances.

• near hearths and open fireplaces.

• near ventilation shafts, since the stream of

air could possibly prevent smoke from

reaching the detector.

• near fluorescent and energy-saving lamps,

since the starter can trigger false alarms

due to the electrical fields caused by

turning the lamp on (minimum distance:

50 cm).

• in rooms where temperatures are below

+5°C or above +45°C.

Installation and commissioning

Remove the two spacers from the socket.

Otherwise, locking of the smoke detector is

not possible.

1. Install the socket e with the included

installation material.

2. Use the spacers f, if the linking line of

several smoke detectors is "surface-

mounted".

3. If needed, carry out the appropriate steps to

link several smoke detectors.

For this, read the chapter "Linking smoke

detectors".

4. Connect the 9V block battery i to the battery

connection and insert the battery into battery

bracket.

5. Stick the smoke detector c into the socket

and lock it by turning slightly clockwise.

Caution: If no battery is inserted, the smoke

detector cannot be fixed in the socket.

6. Carry out a function test.

c Smoke detector

d Connection block

e Socket

f Spacers

g Plug

h Screw

i Battery (9V)

j Test button
