2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |

GLOBE FOOD EQUIPMENT COMPANY

Project Name: AIA#:

Model #: Location:

Item #: Quantity:

12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.

Approved by: Date:

Globe® 60 Quart Planetary Floor Mixer SP62P-4

Model

o SP62P-4

Standard Features

• Powerful 3 HP ﬁxed speed custom built motor

• Direct gear-driven, high-torque transmission

• Heat-treated hardened steel alloy gears and shafts

• Four ﬁxed speeds

• Handles up to 50 lbs. of ﬂour (80 lb. batch size)

• Safety interlocked power bowl lift

• Permanently lubricated oil bath transmission

• Thermal overload protection

• Front-mounted touch pad controls with 60-minute

digital timer and last-batch recall

• Stainless steel, interlocking bowl guard with built-in,

fully welded ingredient chute

• Heavy duty bowl truck (pictured)

• Rigid cast iron body

• Industry standard #12 attachment hub

• NSF approved enamel gray paint

• 6-foot cord and ground plug

• Auto shut off, for improved protection of motor and

transmission protection

Standard Accessories/Attachments

• 60 qt. stainless steel bowl (#304 series)

• Aluminum spiral dough hook, ﬂat beater and stainless

steel whip

• Non-slip rubber feet

• Bowl truck

Warranty

• Two years parts and labor

Optional Attachments/Accessories

• Seismic ﬂange kit

• Slicer/shredder/grater for #12 hub

• Meat grinder for #12 hub

• Meat tenderizer for #12 hub

• Strip cutter for #12 hub

• Bowl Scraper

• Additional bowl truck

• Correctional package

• Extended warranty

To select options see back

Enhanced to handle a

variety of mixes!

Utilizing 4 speeds, operator-friendly power bowl

lift and front-mounted touch pad control panel

with digital timer and heavy duty transmission.

60 Quart Planetary Floor

Mixer with Power Bowl Lift

2153 Dryden Rd., Dayton, OH 45439 937-299-5493 800-347-5423 Fax: 937-299-4147 www.globefoodequip.com | | | |

12/19/2023 Printed in the U.S. © Globe Food Equipment Company Specifications are subject to change without notice.

60 Quart Planetary Floor Mixer SP62P-4

DIMENSIONS | SHIPPING INFORMATION

Reinforced carton for shipping. The weight and dimensions of this reinforced carton are included below and may vary from shipment to shipment.

This product ships on a pallet. Freight class 85.

Model Overall Dimensions Net Weight Shipping Dimensions Shipping Weight

SP62P-4

30.25" W x 41.6" D x 60" H

(76.83 cm x 105.66 cm x 152.4 cm)

980 lbs

(444 kg)

48'' W x 48'' D x 76'' H

(122 cm x 122 cm x 193 cm)

1,228 lbs

(556 kg)

Mixer is constructed of a rigid cast iron body with front-mounted controls, and 60-minute digital timer. Mixer has 3 HP custom built motor with

overload protection and direct gear-driven, high torque permanently lubricated 4 speed transmission consisting of heat-treated hardened steel

alloy gears and shafts. Mixer comes with 60 qt. stainless steel bowl, aluminum bowl truck and stainless steel wire whip, aluminum dough hook

and non-slip rubber feet. Interlocked with stainless steel bowl guard with fully welded ingredient chute. Mixer has #12 attachment hub and

interlocked power bowl lift. Mixer is NSF and ETL listed. Two-year parts and labor warranty.

OPTIONAL MIXER ACCESSORIES AND HUB ATTACHMENTS

MIXER:

XXSEISMIC KIT-LG Seismic kit

60 qt. stainless steel XXBOWL-62

(S/S) bowl

XXBEAT-62 Alum. ﬂat beater

XXHOOK-62 Alum. dough hook

S/S wire whipXXWHIP-62

XBTRUCK-62 Heavy-duty bowl truck

HUB:

XVSGH 9" Slicer/Shredder/Grater

housing only (no plates included-must

select from plates listed on this sheet)

Adjustable slicing plate XASP

(for vegetables only)

Plate holder XPH

Meat Tenderizer attachmentL00670

L00783 Strip Cutter attachment

Shredding Plates:

3/32" (2.3 mm) XSP332*

XSP316* 3/16" (4.7 mm)

1/4" (6.3 mm)XSP14*

XSP516* 5/16" (7.9 mm)

1/2" (12.7 mm)XSP12*

Grating plate XGP*

*Only 1 plate holder required

XMCA-SS Meat grinder assembly

(Polished stainless steel cylinder, worm

gear, ring, and s/s pan. Includes knife,

3/16" plate, and pusher.)

XXCK Chopper knife for XMCA-SS

Chopper Plate Sizes Available:

CP02-12 1/16" (2 mm)

5/32" (4 mm)CP04-12

CP05-12 3/16" (5 mm)

1/4" (6 mm)CP06-12

5/16" (8 mm)CP08-12

CP10-12 3/8" (10 mm)

CP12-12 1/2" (12 mm)

CP14-12 9/16" (14 mm)

CP16-12 5/8" (16 mm)

CP18-12 11/16" (18 mm)

CP00-12 Stufﬁng plate

1/2" Stufﬁng tube (mutton)XST12

3/4" Stufﬁng tube (pork)XST34

FACTORY INSTALLED OPTION:

XXCORR-62 Correctional package,

includes tamper resistant external

fasteners.

EXTENDED WARRANTY

SP-XDSPL Extended warranty for

SP62P mixer, extends factory warranty

to 3-years. Available only at time

of purchase.

38.6 (98)

60 (152.4)

30.25 (76.8)

3.0 (8)

SPECIFICATIONS

Model Motor Volts Amps Transmission Type Capacity Controls

Power

Bowl Lift

Agitator Speeds (RPMs) Attachment Speeds (RPMs)

First Second First Second

SP62P-4

(1 Phase)

3 HP 220/60/1 18 Gear 60 qt / 57 liter

Digital,

front

mounted

timer and

controls

1/8 HP

Motor

60 105 67 118

SP62P-4

(3 Phase)

3 HP 208/60/3 12 Gear 60 qt / 57 liter

Third Fourth Third Fourth

176 310 198 349

Cord & Plug: Attached 6-foot exible 3-wire cord with molded plug ts a grounded receptacle. Single phase NEMA L6-30P Three phase NEMA L15-20P

*Specify voltage when ordering.
